Home > Products > New Products > PP STRAPPING BAND PRODUCTION LINE/POLYPROPYLENE STRAPS EXTRUDER
PP STRAPPING BAND PRODUCTION LINE/POLYPROPYLENE STRAPS EXTRUDER
USD $10,000 - $1,000,000
/ Set
1 Set(Min.Order)
- 50 Set / Sets per Month
- SHANGHAI
You May Like
-
PU Pipe Complete Extrusion Line/machinery for polyurethane products
-
plastic staple fiber production line (5 tons P.D. )/small capacity polyester staple fiber making machinery/hollow and cotton typ
-
polyester staple fiber making line /cotton type staple fiber machine
-
PC WAVE SHEET EXTRUDER,TRANSPARENT PC WAVE SHEET/PANEL MAKING LINE/ PC TRANSPARENT ROOF SHEET MAKING MACHINERY
-
PET Bottle Recycling Line /plastic recycle line/recycling machine
-
CE STANDARD FIBERGLASS PPR PIPE PRODUCTION LINE
Product Details
| Condition | New | Application | Film | |
| Plastic Processed | Polystyrene | Screw Design | Double-screw | |
| Automatic Grade | AUTO | Place of Origin | Shanghai, China | |
| Brand Name | CISSCO | Model Number | CS | |
| Voltage | 380V | Power(W) | 200KW | |
| Dimension(L*W*H) | 2000MM | Weight | 30T | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
PP STRAPPING BAND PRODUCTION LINE/POLYPROPYLENE STRAPS EXTRUDER1.HIGH QUALITY
2. LEADING TECHNOLOGY
PP STRAPPING BAND PRODUCTION LINE/POLYPROPYLENE STRAPS EXTRUDER
I. OVERVIEW
- 1. Power380v/3P/50Hz
- 2. MaterialPP
- 3. Extruding capacity120-150kg/h
NOTE: The extruding capacity may be changed as a result of the processing materials and different process conditions.
- 4. Product specificationwidth 5-19mm, thickness 0.4-1.0mm
- 5. Quantity of straps one time4 straps (Width: 5-12mm)
2 straps (Width: 15-19mm)
- 6. Speedmax.140m/min
- 7. Mid-height of extruder1000 mm
- 8. Control DirectionFrom left to right
- 9. Total power155kw (Energy consumption: Appro.95kw)
- 10. Humidity≤85%
- 11. Temperature0-40°C
- 12. Cooling cycling water≤20°C ≥0.3Mpa ~30T/h
- 13. Compressed air0.4m³/min>0.5MPa
- 14. Overall dimension32m×3m×4.2m
- 15. Output parameters example (for reference)
Strap width (mm) | Strap thickness (mm) | Strap weight (gr/mt) | Strap quantity | Speed (mt/min) | Production (kg/h) |
5 | 0.5 | 1.6 | 4 | 140 | 67 |
9 | 0.6 | 3.2 | 4 | 140 | 134 |
12 | 0.6 | 5.3 | 4 | 125 | 150 |
15 | 0.6 | 6.6 | 4 | 100 | 150 |
15 | 0.8 | 8.8 | 2 | 140 | 148 |
19 | 0.85 | 11.5 | 2 | 109 | 150 |
PICTURES
