CE Standard PVC Foaming Plate Extrusion Machine
- 20 Set / Sets per Month
- Shanghai
- T/T
-
Lightweight thermal insulation house prefabricated wall panel price
-
Mgo Sound insulation and heat preservation concrete hollow lightweight partition wall panels
-
lightweight partition wall panel
-
building material Mgo precast wall panels
-
Mgo lightweight concrete foam wall panels
Quality Choice
-
Supply perforated/acoustic/sound-absorb wall panel mgo board/fireproof mgo board/magnesium oxide board
Product Details
| Condition: | New | Product Type: | Plastic Sheet | Place of Origin: | Shanghai, China |
| Brand Name: | PVC foaming plate extrusion machine | Model Number: | PVC foaming plate extrusion machine | Voltage: | 380v |
| Power(W): | 200kw | Dimension(L*W*H): | 30m*3m*3m | Weight: | 20tons |
| Certification: | CE | Warranty: | 1year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
PVC Foaming Plate Extrusion Machine
I. OVERVIEW OF PVC FOAM PLATE EXTRUSION LINE
1. Technical criteria:
1.1 Material: PVC powder
1.2. Product width: L=1000-2000mm;
1.3. Thickness: δ=2~18mm;
1.4. Max. Output: 500kg/h
2. Electricity
2.1. Designation: 380V/ 3 P/ 50 Hz
2.2. Protective measure: earth
3. Compressed air:
3.1. Effective working pressure: 0.4~0.6Mpa
3.2. Quality: condensing-free, oil-free, dust-free, pre-filtered.
4. Cooling water
4.1. Effective working pressure: 0.2~0.4Mpa
4.2. Water temperature: 10 ~ 25 degree centigrade.
II. SUPPLY SCOPE OF PVC FOAM PLATE EXTRUSION LINE
Code | Name | Qty. |
1 | SJZ-80/156B TWIN CONICAL SCREW EXTRUDER | 1 SET |
2 | EXTRUDING DIE WITH TEMPERATURE CONTROLLER | 1 SET |
3 | 3-ROLLERS CALENDER | 1 SET |
4 | 3-ROLLERS TEMPERATURE CONTROLLER DEVICE | 1 SET |
5 | COOLING BRACKET | 1 SET |
6 | EDGE BLADE CUTTER | 1 SET |
7 | HAUL-OFF UNIT | 1 SET |
8 | SAW CUTTER | 1 SET |
9 | STACKER | 1 SET |
10 | AUXILIARY EQUIPMENT | 1 SET |
III. PICTURES OF PVC FOAM PLATE EXTRUSION LINE
• We design, engineer and manufacture and customized the extrusion line.
• Choosing the right solution: In plastics manufacturing, process is everything. We carefully evaluate each project's requirements, weigh the options and recommend the best solution for the client.
• Training & Development: we offer extensive start-up assistance, comprehensive training. As well as Engineers for training and installation at our client’s factory
• Support: We support the client in all the stages of the project life cycle, as well as the constant spare parts supply in a time efficient manner.
