Vacuum Drying Oven DZ Functional Form vacuum chamber price

Specifications

Vacuum Drying Oven
1.Passed ISO 9001.2008
2.Fast delivery
3.Very competitive price
4.Accuracy

Vacuum Drying Oven



Uses:
      This product is designed for drying and heating powder articles, as well as disinfecting and sterilizing of glass containers. With characteristics of short warming up times, low pollution and non-destructive drying, it is widely used in the field of medicine, food, light industry, chemistry, agriculture, environmental protection and experiment etc.



Characteristics(Functional form):

1. Integrated design of vacuum oven, pump and other relative device, which is easy to operate and stable in performance.
2. Auto-pumping can be achieved by setting vacuum degree as needs; multiple sections of program can be preset to ensure repeated or multistep pumping. With experiment goes on, the vacuum degree decreases, and then the controller would restart the pump according to showed error to ensure stable and accurate vacuum degree.
3. Manual and electric double air eliminator, which enable easy operation of air bleeding; manual air-bleed is used on the occasion of power failure.
4. Pump line with air filter inside to ensure long service life of vacuum pump.
5. Vacuum degree is shown by digital meter and pointer meter.



Optional unction:

1. RS-485 /232 connector , can contact with the computer

2. Typer (minisize)

3.Alarm system when electric cut off

4 Cut off electric or alarm function when leakage

5 N2 inflation inlet

6 Vacuum solenoid



Working condition :

1. Envirnment Te.: 5~40°C

2 Humidity : ≤85%RH

3. voltage 220V±10V , 50±1HZ

4. There was no shake of the incubator and not cauatic air around the chamber.



Main Technical Parameters:



Model	DZ-1A(BC)Ⅱ	DZ-2A(BC)Ⅱ	DZ-3A(BC)Ⅱ
Voltage	220V/50Hz
Consumed power	800W	1400W	2000W
Temperature variation	RT+10~250°C
Temperature distinguishability	0.1°C
Temperature fluctuation	±1%
Vacuum degree	<133pa
Interior dimensions(mm)	300×300×270	415×370×340	450×450×450
Exterior dimensions(mm)	480×480×605	560×540×680	640×590×780
Packaging dimensions(mm)	620×560×720	730×640×790	790×750×960
Net/gross weight (kg)	42/52	67/92	82/105



Model	DZ-2BE	DZ-3BE
Voltage	220V/50Hz
Consumed power	1400W	2000W
Temperature variation	RT+10~250°C
Temperature distinguishability	0.1°C
Temperature fluctuation	±1%
Vacuum degree	<133pa
Interior dimensions(mm)	415×370×340	450×450×450
Exterior dimensions(mm)	560×540×1330	610×620×1350
Packaging dimensions(mm)	735×630×1470	785×710×1490
Net/gross weight (kg)	85/115	86/117



Pictures:



Packing:





Company warehouse

Tianjin City Taisite Instrument Co.,ltd

Amanda



Mobil: 0086-15122693573

Skype: amandawang08

Fax: 0086-022-67683108



With the best price and high quantity service, we believe we could be your best supplier.

We are sincerely looking forward to cooperating with you
