Help CenterPulp Paper Molding Egg Tray Machine With 16 Pieces Molds
Related Products
-
Automatic Paper Pulp Moulding Egg Carton Making MachineUS$ 20,000 - 155,000MOQ: 2 Sets -
Small Egg Carton Making MachineUS$ 2,000 - 55,000MOQ: 1 Set
-
Egg Tray Making Machine Small in ChangzhouUS$ 155,000 - 179,000MOQ: 1 Set
-
Making Machine Egg Tray Cartons Egg Tray Making Machine in JapanUS$ 155,000 - 185,000MOQ: 1 Set
-
Egg Carton Machine Pulp Molding MachineUS$ 155,000 - 185,000MOQ: 1 Set
Specifications
Output :3500-4500 pices/hourMolds:32 molds
material : paper ,waster paper,
Best quality with reasonable price
Paper egg tray machine supplier in china
Tel: 86-311-8205285 Mob: 86-15131163806
Shijiazhuang Haichuan Machinery The first manufacturer to sell and produce egg tray machine in Shijiazhuang CIty . We have the strong scientifc research in improving the prodcution process . Now Our technical team can make high effciency ,save enery egg tray machine . And The most improtant , we not only have the machine product factory and workshop , but also we have the egg tray production line . You would learn the egg tray making process , and also we would find the machine problems , and improve the egg tray machine quality .
1. pulp molding system: hydraulic pulper, High-frequency vibration sieve frame, Pulp pump, Strengthening of self-priming pump, Agitator, Control cabinet for pulping system
2. forming system: Rotary forming machine, Molds, Roots vacuum pump, Screw Air Compressor, Vacuum buffer tank, Air compressor storage tank, White Water pump, High-pressure water pump, Refiner machine, Power cabinet for forming system
3. drying system: Conveyor, Blower, induced fan, Burner, Bellows, etc
4. packing system: baling machine
|
Type
|
Mold |
Capacity |
Power |
Plant area |
consumption |
Labor |
|
HCS01
|
4 |
1000pcs/h |
33.5kw |
More than 300 square meter |
2ton/24hours (coal) |
3-4peoples |
HCM01 |
16
|
2000-2500pcs/h |
60kw |
More than 500 square meter |
2.2ton/24hours (coal) |
4-6 peoples |
|
HCL01
|
32 |
3000-4000pcs/h |
116kw |
More than 600 square meter |
2.5ton/24hours (coal) |
4-6 peoples |
Advantage: 1.high efficiency 2. low failure rate 3.using less labor 4. simple operation
Machinery of egg tray machine :
Dryer of civil dryer :
Haichuan egg tray machine progressing :
