Product introduction:
Microwave digestion, as a high efficient sample preparation method, has advantages of fast heating, uniform heating performance, minimal reagent use, lower reagent blank, energy Saving and high efficiency. It keeps sample for volatile element analysis testing .It is widely used in food, textile, Geology, metallurgy, coal, biological medicine, petroleum chemistry, environment monitoring, sewage treatment, battery manufacturing fields.
Features:
Set standard curves according to pressure and time and display on the touch-screen
Test Pressure without, real-time monitoring and display pressure of the digestion vessel
Set digestion pressure and time according to different requirements
Set corresponding pressure protection in accordance with different conditions
Users can set parameters in various functions according to their own requirements
Different models can realize: high pressure digestion, multi-vessel closed digestion, confined organic
synthesis.
Can edit, and store 255 digestion programs; each method can set up 10 digestion procedure
Realize 360°rotation of digestion vessel to solve uniformity problem.
High- frequency and resonance type programming; Users can set 0-1000W according to their requirements.
Automatic calibration for different parameters and basic troubleshooting function
Technical Specifications:
Model | MWD-S01 | MWD-D01 | |
Pressure Control | Full Scanning | ||
Temperature Control | No | Full Scanning | |
Vessel Volume | 60ml | ||
Pressure Testing | Non-Touching | ||
Temperature Testing | No | Non-Touching | |
Digestion Vessel | 6 | ||
Vessel Material | Inner Vessel: Imported TFM; Outer Vessel: Imported PEEK+ glass fiber | ||
Maximum Working Pressure | 5 MPa | ||
Pressure Limit | 6 MPa | ||
Maximum Working Temperature | 250℃ | ||
Temperature Limit | 300℃ | ||
Outer Vessel Pressure Limit | 10 MPa | ||
Screen | 7 Inch Touch Screen | ||
Pressure Control Range | 0-5 MPa (0-50kg/cm2) | ||
Pressure Control Accuracy | 0.1MPa(1kg/cm2) | ||
Microwave Power | 1000 W, set from 0-1000W according to requirements | ||
Microwave Frequency | 2450MHz | ||
Chamber exhaust system | High-power Blower, exhaust speed>5cbm/min | ||
Rotation Type | 360° continuous rotation | ||
Microwave Leakage | <5mW/ cm2 | ||
Power | AC 220V,10A,50/60Hz | ||
Size | 520mm×400mm×460mm | ||
Weight | 30kg | ||
A & E Lab.
A & E Lab Hot Selling are include: UV VIS Spectrophotometer, Visible Spectrophotometer, Flame Photometer, PCR-Cycler, Blocker Heater, Hotplate, Stirrer, Stirrer Hotplate, Rotory Mixer, Tube Roller Mixer, 3D Rocker, See-Saw Rocker, Vortex Mixer, Orbital Shaker, Cold Keeper, Melting Point Device, Electronic pipette, etc.
Welcome to inquire us!
The information of our instruments:
Warranty : 1 year
Certifications: CE&ISO
Delivery time: Within 10 days after received your payment. (AAS: Within one month)
MOQ: 1 unit
Payment term: T/T advance, paypal, western union, Moneygram.
Cooperation type: Distribute / Neutral packing / OEM / ODM.
