Online Digital Turbidity Sensor
A & E Lab hot selling are include: UV VIS Spectrophotometer, Visible Spectrophotometer, Flame Photometer, PCR-Cycler, Blocker Heater, Hotplate, Stirrer, Stirrer Hotplate, Rotory Mixer, Tube Roller Mixer, 3D Rocker, See-Saw Rocker, Vortex Mixer, Orbital Shaker, Cold Keeper, Melting Point Device, Shaker Incubator, ect.
Online Digital Turbidity Sensor
Feature
Application : Water and wastewater treatment, drinking water and surface water monitoring, chemical process, recycling water,and scrubber.
9 0-degree of the optical detection principle.
Color and bubbles without interference,build in self-clean system.
5 -points calibration, single-point calibration can be analyzed based on laboratory or field.
Stainless steel housing and hard to scratch lenses.
Panel or Wall mounts Enclosures, NEMA4 X, IP6 5 water proof, dust proof.
Providing grounding function,prevent sample charged interference.
Large LCD with Auto/Manual background illumination screen.
Password protections prevent unauthorized of setting.
RS-48 5 interface communication (AE-TO-3, AE-TO-4 ).
Scaleable isolate d output: 0/4 ~20mA.
Two separate mechanical relays for high and low (HH/HL/LL) set points.
Separately adjustable high and low set-point hysteresis (dead bands) prevent chattering of relays around the set point.
The third mechanical relays for electrode self-cleaning or alarm.
Technical Specifications
| Model | AE-TO-1 | AE-TO-2 | AE-TO-3 | AE-TO-4 |
| Range | Turbidity / Suspended Solid(SS) / (MLSS) | |||
| Turbidity Unit | NTU,FTU,FNU | |||
| SS Unit | ppm, mg/L |
|||
| MLSS Unit | g/L | |||
| Turbidity Range | 0.00-20.00,20.0-100.0 / 0.0-200.0,200-500 / 0-3000 NTU (depends on sensor) | |||
| SS Range | 0~1000 mg/L | |||
| MLSS Range | 0.0-50.0 g/L | |||
| Resolution | Auto (0.01,0.1,1) | |||
| Analog Output | 2 sets 0/4 ~ 20mA | 1 set 0/4-20mA | ||
| Serial Interface | RS-485 | |||
| Relay Specification | 2SPST/240VAC0.5A | |||
| Frequency of Cleaning Time | ON 0-9999 sec / OFF 0-999.9 hours | |||
| Operation Temperature | 0~50°C | |||
| Power Supply | 00~240VAC±10% 50/60Hz | 20-30VDC | 100~240VAC±10% 50/60Hz | 20-30VDC |
| Size / Weight | 144mmxl44mmxll5mm / 800g | |||
| Installation Size | 138mmxl38mm | |||
Product picture
