Specifications
Lab Scale 3D Gyration Rockers1.MOQ: 1 PC
2.Warranty: 1 year
3.Delivery Time: within 5-7 days after received your payment.
A & E Lab.
Main Products: Atomic Absorption Spectrometer (AAS), Fluorescence Spectrophotometer,
Bio-Spectrophotometer, UV Vis Spectrophotometer, Visible Spectrophotometer, Flame Photometer, Whiteness Meter, Turbidity Meter, Colorimeter, Gloss Meter, Tintometer, Automatic Polarimeter, Auto Melting Point Apparatus, Automatic Refractometer, Abbe Refractometer, PH/DDS/TDS Meter, Incubator, shaker, Hotplate, Mixer, PCR, Oven, etc.
Lab Scale 3D Gyration Rockers
Application:
The 3D gyration rockers are designed to generate in three dimension rocking motion with smooth and full mixing action. The rockers are ideal for low foaming agitating, and widely used in DNA extractions, staining and de-staining procedures.
The tilted angle can be adjusted manually from 3 to 12 degree. With a large platform, the rockers can accommodate large vessels such as culture flasks, petri dishes etc. The non-slip matt on the tray can prevent vessels slipping away during agitation.
Rockers are often used in conjunction with incubators and environmental chambers and can be used in temperatures up to 40°C and humidity up to 80%.
There are two models for this type of the rocker: Both of them are microprocessor controlled. The digital model (AGRL2) provides digital timer with up to 9 hours setting and speed control in 1rpm increment.
The AGRL1 model provides 2-hours timers (in 10 minute integral) and 10 steps speed control without digital display as shown in MOS.
The AGRL2 model provides a good safety feature: when the motor stalled or overload, the unit will stop, beep and show error message in the LED display.
Technical Specification:
Model |
AGRL1 |
AGRL2 |
Speed Range (rpm) |
5 to 70 |
5 to 70 |
Rocking Type |
3D gyration |
3D gyration |
Platform Dimensions (mm, WXL) |
355x355 |
355x355 |
Tilting Angle (degree) |
3-12 |
3-12 |
Angle Adjustable |
YES |
YES |
Timer (min) |
120 |
Digital 540 |
Speed Control Mode |
10 integral selection |
digital in 1 rpm increment |
Maximum Load (KG) |
10 |
10 |
Dimensions (mm, WXLXH) |
360x420x210 |
360x420x210 |
Operation Temp. Range (°C ) |
+4 to +40 |
+4 to +40 |
Maximum Operation Humidity |
80% |
80% |
Net Weight (KG) |
10 |
10 |
Power Supply |
230V, 50Hz, 50W |
|
