1Automatic Machine Lab See-saw Rockers Rocking2.Certificate:ISO,CE.
3.Warranty:1years.
A & E Lab Hot Selling are include:
UV VIS Spectrophotometer, Visible Spectrophotometer, Flame Photometer, PCR-Cycler, Melting Point Device, Blocker Heater, Hotplate, Stirrer, Stirrer Hotplate, Rotory Mixer, Tube Roller
Mixer, 3D Rocker, See-Saw Rocker, Vortex Mixer, Orbital Shaker, Cold Keeper, Shaker Incubator, etc.
Welcome to inquire us!
Lab See-saw Rockers Rocking Automatic Machine
ASRL3
Application:
The ASRL3 and ASRL4 use a see-saw motion to create wave-like mixing process. The mixers are
specially design for any flat vessels, such as culture flasks, Petri dishes etc., generating a gentle
and full mixing action.
More platforms can be added to the rockers by adding stacking system to accommodate more samples.
There are two models for this type of the rocker: Both of them are microprocessor controlled.
The digital model (ASRL4) provides digital timer with up to 9 hours setting and
speed control in 1rpm increment.
The ASRL3 model provides 2-hours timers (in 10 minute integral) and 10 steps speed control without
digital display as shown in MOS.
The ASRL4 model provides a good safety feature: when the motor stalled or overload,
the unit will stop, beep and show error message in the LED display.
Technical Specification:
Model | ASRL3 | ASRL4 |
Speed Range (rpm) | 5 to 70 | 5 to 70 |
Rocking Type | See-saw, wave | See-saw, wave |
Platform Dimensions (mm, WXL) | 355x355 | 355x355 |
Tilting Angle (degree) | 7 | 7 |
Angle Adjustable | No, fixed at 7º | No, fixed at 7º |
Timer (min) | 120 | Digital 540 |
Speed Control Mode | 10 integral selection | digital in 1 rpm increment |
Maximum Load (KG) | 10 | 10 |
Dimensions (mm, WXLXH) | 360x420x180 | 360x420x180 |
Operation Temp. Range (°C ) | +4 to +40 | +4 to +40 |
Maximum Operation Humidity | 80% | 80% |
Net Weight (KG) | 10 | 10 |
Power Supply | 230V, 50Hz, 50W | |
Product Show:
