A & E Lab main products include:
UV Visible Spectrophotometer, Visible Spectrophotometer, PCR, Stirrer hotplates, Melting Point Device, Shaker, Rocker, Block Heater, Mixers, pH/ORP/TDS/DO Meter, etc
Our goods have been CE certificated, guaranteed by warrranty and exported to every country of the world with high quality and good services.
Pls don't hesitate, A & E Lab products are worth a try!
Welcome to inquire us!
About Hotplate Stirrer (ASHC-304)
Heating Control:
- Proportional Voltage or Thermal- Regulator: Simple, Economic, Less Accuracy
- PID control: Accurate, Stable
- Additional external sensors in digital display models: used for monitoring or controlling the solution temperature
- "Safe sample temp lock" function in advanced models: machines turned off if temperature >3℃ of the set temperature
- Timer: up to 999 minutes can be set for setting
Stirring Control:
- Control the speed with sensors: Constant speed, No disengagement of the stir bar, Gradual increase in speed
- Brushless motors used in the digital display modes: Independent from the input voltage, Constant speed, No disengagement of the stir bar, Gradual increase in speed
- Step motors in low speed: Gentle, low movement
Technical Specifications:
Model | ASHC-301 | ASHC-302 | ASHC-303 | ASHC-304 | ASHC-305 | ASHC-306 | ||
Control | Analog | Analog | Digital Heating and Stirring | Digital Heating and Stirring | Digital heating, Analog stirring | Digital heating, Analog stirring | ||
Plate (mm) | 160x160 | 300x300 | 160x160 | 300x300 | 160x160 | 300x300 | ||
Max. Temp(℃) | 550 | 550 | 550 | 550 | 550 | 550 | ||
Stirrer Speed(rpm) | 150-1500 | 150-1500 | 150-1500 | 150-1500 | 150-1500 | 150-1500 | ||
Power Supply | 230V,50HZ or 110V,60Hz | |||||||
Dimension (mm) | 220x240x145 | 330x380x145 | 220x240x145 | 330x380x145 | 220x240x145 | 330x380x145 | ||
