Home > Packaging & Printing > Printing Machinery > Heat Press Machine > Plate Heat Press Machine

Plate Heat Press Machine

Name: Plate Heat Press Machine
Brand: Disen
SKU: 141154114
Availability: InStock

Guangzhou Disen Science Technology Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Plate Type:

Gravure

Place of Origin:

Guangdong, China

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Plate Type Gravure

Place of Origin Guangdong, China

Brand Name Disen

Model Number DS-Plate

Usage Paper Printer

Automatic Grade Semi-Automatic

Voltage 110V/220V, 110v / 220v

Gross Power 350W

Dimensions(L*W*H) 40*20*50cm

Weight 12 KG

Certification CE Certificate

After-sales Service Provided Engineers available to service machinery overseas

Customer First Service First

1. Introduction
Any colorful photos, scenery pictures can be transferred printing into coated plates that are particularly suitable for advertising, gifts, promotion, personalized products etc. Simple and quick operation, continuing working ability and highly automatic property, meanwhile the machine can transfer photo on Coated board, coated metal board, coated key ring and coated mirror.

2. Feature
(1) Meter controller makes the heating effect much more steady.
(2) Imported silica gel heating pad is able to endure high temperature. To make the pressure more uniform and will not be metamorphosed when the temperature reaches 240°C.
(3) Highly electronic resistance equipment which makes the temperature error to be 1°C.
(4) Convenient to adjust the pressure with the rolling screw.
(5) The biggest transfer size: 8 inch (diameter of the plate)
(6) Preheating time ( Room Temperature of 20°C): 1-3 minutes. Temperature status will be showed in the mean while.
(7) Fashionable look with small weight makes it flexible to bring with

3.Technical Parameter

Voltage: 110v / 220v

Power: 350w

Time Range: 0-99 sec

Temperature Range: 0-240°C

Resolution: 1 s and 1°C

Size: 40cm (L) x 20cm (W) x 50cm (H)

G.W: 12 KG

Customer First Service First

Plate heat press machine

Customer First Service First

Operation Process

(1)Mirror print the picture on normal printing paper with sublimation ink.

Notice: The machine should be connected with ground wire! Should not have much pressure on the machine, otherwise the heating pad will be metamorphosed. Make sure the size of the photo is the same with the surface of the plate while putting the photo onto the plate.

(2) Put the picture onto the plate

(3) Put the plate on the middle part of the plate holder

(4) Adjust the pressure with the rolling screw under the plate holder

(5) Hold the plate and press the handle

(6) Set up the heating temperature to 180°C

(7) Set up the heating time to 30 s

(8) Switch on power. (Power indicator will turn on green)

(9) Waiting until the temperature reach to 180°C( temperature indicator will turn on red )

(10) Switch on timer for heat transferring

(11) Warning automatically after 30 s

(12) Switch the power off

(13) Stretch the handle to open the holder and then take out the plate

(14) Finished photo transferring on plate
plate heat press machine, digital plate heat press machine ,heat press machine for plate .

Function

Press Handle
Heating Pad
Holder and Pressure Adjusting Screw
Meter Display for Timer
Temperature Indicator
On/off Function for Timer
Power On/Off
Power Indicator
Meter Display for Temperature

Troubleshooting

Style	Problems	Cause	Resolution
Troubles of the machine	No indication after press the Power switch	The fuse broken	Replace the same standard fuse
	The fuse always broken	The load of fuse is too small or part short circuit of the heating pad	Replace the fuse or heating pad
	There is an indication of the power but the machine do not heat	Short circuit of the heating pad	Replace the heating pad or send it to our company for repair
	Incorrect LED indication or no indication	Have problem with the meter	Replace or send it to our company for repair
operation	The color of the photo is dim	Heat transferring time is too short	Increase heat transferring time
	The photo is mistiness	Too long heat transferring time leads the printing ink diffuse.	Decrease heat transferring time
	The color of parts of the photo is light	Not enough pressure or the coat is not uniformity	Increase the pressure or replace the plate
	Photo is mistiness in the same part of the plate	Heat pad local parts problem	Replace the heating pad
	Picture ink uneven	Ceramic diameter Up and down different	Replace the plate

Accessories

(1)The Printer. Choose any normal Ink Jet photo printer and Epson series printer is recommended.
(2)To achieve the best quality of the photo printing, the following printer setting for your reference:
a.Choose the “Best Photo” and the “Photo Quality Ink Jet Paper” under “Main” as shown in figure 1.
b.Click “Advanced” under “Main” to achieve more setting as shown in figure 2.
c.Choose “Mirror Image” under “ Page Layout” as shown in figure 3 while printing photo for ceramic board and metal board, shell board and imitative ceramic necklace etc.
plate heat press machine, digital plate heat press machine ,heat press machine for plate.

(3)The sublimation ink. Make sure to pull out the color soft plug on the top of the ink cartridges before putting them into the printer. The sublimation ink is easy to dry and better to furnish with one printer until the ink use up.
(4)Ink and printer maintenance.
a.Choose “ Maintenance” under the “Property” of the printer to make maintenance for the printer as shown in figure 4.
b.Use the three buttons on the printer. Ink empty hint. The power light and the ink button are on. (if the ink button keep on flashing, the ink is going to be used up but not yet empty. Replace the empty ink cartridge. Press the ink button. The print head moves to the ink cartridge check position and the power light begins to flash. The ink cartridge indicated by the mark is either empty or low. If more than one ink cartridge is empty or low, the print head moves to the mark. This occurs each time the ink button is pressed until all empty or low ink cartridges have been indicated. Once all of the empty or low ink cartridges have been indicated, the print head moves to the ink cartridge replacement position when the ink button is pressed. Cleaning the print head. Press the ink button for more than three seconds and the printer starts cleaning the print head.
(5)Photo printing. Select the image you need in the computer to print out. Make sure the pixel of the photo is more than 200 to achieve the better heat transferring effect. Please do not touch the printing side of the sublimation paper after printing within 1 minute.
(6)Ink leak. Take tissue to absorb the ink or need to get maintenance from Epson shops.
(7)The printed color is not matched with the original color of the photo. Clean the print head or change a new ink cartridge.
(8)One printer can fill with sublimation ink and normal photo printing ink. But the better way is only fill with one kind of ink in one printer.
plate heat press machine, digital plate heat press machine ,heat press machine for plate .

Warranty and Maintenance:

1,One-year guarantee.
2,Pressure: Adjust pressure screw clockwise to increase the pressure, counter clockwise to decrease the pressure
3,Time: Check and adjust the position of the jiggle switch in the rear machine case if the buzzer not warn or keep warning when time is out.
4,If press the pressure handle,the handle would be spring back automatically, please adjust the adjusting screw downward. After finished the printing, the handle may be too heavy to hold up, please adjust the adjusting screw upward.
5,Please check the circuit while the heat board is not available after the machine was on several minutes.
6,The natural life of the Silica Gel Board is 10000 times working.
7,The natural life of the Heat Board is 10000 times working.
8,Please feel free to contact us without any delay if there is any problem in the quality.
plate heat press machine, digital plate heat press machine ,heat press machine for plate .

Notice:
1. The machine must be connected with the ground wire!
2. Do not touch the heat board while heating!
3. Do not touch the heat board once finish working as time is needed to cool down.
4. Please keep children away from the machine!
5. Please use the heat insulation glove to pick the finished goods!
