Automatic Small Format 600*600mm Glass Photo Crystal Printing Machine

Automatic Small Format 600*600mm Glass Photo Crystal Printing Machine thumbnail-1
Automatic Small Format 600*600mm Glass Photo Crystal Printing Machine thumbnail-2
Automatic Small Format 600*600mm Glass Photo Crystal Printing Machine thumbnail-3
Automatic Small Format 600*600mm Glass Photo Crystal Printing Machine thumbnail-4
Automatic Small Format 600*600mm Glass Photo Crystal Printing Machine thumbnail-5
Automatic Small Format 600*600mm Glass Photo Crystal Printing Machine thumbnail-6
Automatic Small Format 600*600mm Glass Photo Crystal Printing Machine photo-1
Automatic Small Format 600*600mm Glass Photo Crystal Printing Machine photo-2
Automatic Small Format 600*600mm Glass Photo Crystal Printing Machine photo-3
Automatic Small Format 600*600mm Glass Photo Crystal Printing Machine photo-4
Automatic Small Format 600*600mm Glass Photo Crystal Printing Machine photo-5
Automatic Small Format 600*600mm Glass Photo Crystal Printing Machine photo-6
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Laser Type:
Other, UV Led
Engraving Area:
600*600MM
Contact Supplier Request Quote Chat Now
Guangzhou Disen Science Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou Shenzhen Hongkong Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Laser Type Other, UV Led
Engraving Area 600*600MM
Engraving Speed 1.5-24 squre meter each hour
CNC or Not Yes
Cooling Mode Water Cooling
Applicable Material Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood
Graphic Format Supported BMP, DWG, DXF
Place of Origin Guangdong, China
Brand Name Disen
Model Number DSP-AC6060
Dimension(L*W*H) 107CM*135CM*67CM
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Automatic small format 600*600mm glass photo crystal printing machine

Product Description
Product Name
Factory outlet high quality automatic multifunction 6060 uv flatbed printer
Print size
0.6m*0.6m
Print head
TX800 OR DX5
Print head(s)
1 print head
Print Color
C.M.Y.K+W or C.M.Y.K*2 , 8 nozzles
Print height
100mm
Print accuracy
1440dpi
Print weight
50KG weight precision nondestructive
Print method
Micro piezo technology
Droplet size
Variable-Sized Droplet Technology, Minimum 3.5pl drop
Print speed
1.5-24 squre meter each hour
Print Resolution
4pass,6pass,8pass,12pass,16pass
Power requirement
110-220V 50-60HZ 360W
UV System
UV LED Lamp
Work Environment
Temperature 5-35℃, humidity 20-80RH
Weight
150KG/180KG
Equipment size
107CM*135CM*67CM
Packing
wooden case, fumigation





 Device Features:
 • Versatile, a multi-purpose machine, textile, UV flexible application mode
 • automatic lift platform, easy to operate, reduce the bit error
 • printing mode optional mist or spray line, spraying line speed, mist lifelike drawing and put an end to the bars
 • three sections squeegee and a peristaltic pump device to prevent nozzle clogging and extend nozzle life
 • Automatic nozzle cleaning and moisturizing means, ensure that the ink fluency prevent nozzle clogging
 • You can set any location as print origin, easy to learn
 • Silent linear guide, high precision and stable performance, through the European Union CE certification, quality and more secure
 • The machine prints the platform has the scale, easy to measure visual display printed material
 • Use imported LED-UV lamp, cold light source, no radiation, low power consumption, environmental protection and energy saving
 • adsorption platform, intelligent vacuum suction device can be conveniently blown pick material
 • The machine prints highly customized models based on the actual situation





Detailed Images
