Help CenterHypervelocity ONE PASS Series 230 Square per Hour Industrial UV Printer
Related Products
-
2016 Newest GH2220 Print Head DSP-GJ5038 90x60cm LED UV Flat PrinterNegotiableMOQ: 1 Set -
Multifuntion Dongzhi Sprinkler Head 4+2 Inspiratory Platform 1.5M*1M UV PrinterNegotiableMOQ: 1 Set
-
DX5 Micro-piezoelectric DSP-FB3358 Multifunction uv Flatbed Printer a3NegotiableMOQ: 1 Set
-
Automatic Positioning UV2030 Multifunction 4+2 Dongzhi Nozzle uv Led Flatbed PrinterNegotiableMOQ: 1 Set
-
Adsorption Platform Automatic Cleaning Function UV2513 uv Led PrinterNegotiableMOQ: 1 Set
Print Size |
Valid Width:161mm |
Print Head |
JINGGONG 12PL Print Heads Quantity:12-32(for choice) |
Print Colors |
UV Curable Ink,4-6 Colors for Choice |
Print Height |
80mm |
Print Weight |
Non-destructive Accuracy weight:50KG |
Printing Speed |
24m/Min,18m/min,12m/min 3 level for choice (About 230 square/hr) |
Ink System |
UV Curable Ink(C,M,Y,K+W) |
Automatic Cleaning System |
Automatic Cleaning Function(Intelligent positive pressure and Negative pressure) |
Print Head Technology |
Piezo inkjet printing ink |
Ink Cartridge: |
Continuous ink flow (refillable while printing) /Capacity: 2000ml |
Power Supply |
220V/3500W,50HZ/60HZ |
Applied Materials |
Waist Line,Ceramic,Wood etc |
Curing System |
Mercury |
Color Management |
Admitted to International ICC standard,with Curve Line Function |
Image Format |
TIFF,JPEG,Postscript 3,EPS,PDF etc |
Operating Platform |
Conveying Belt |
USB USB Connector |
Network Transmission |
Guide Rail |
Square Linear Guide Rail |
RIP Software Output |
Main Top |
Operating Platform |
Vacuum Adsorption Platform (Alloy Aluminum Honecomb) |
N/W. |
1550KG |
Equipment Size |
1105*3393*1845(mm) |
|
Product Feature:Continuous flow line printing,24M/Mins. Product Name: ONE PASS series of industrial UV printer Features: Line printing, 24-meter-high yield per minute Product details Print size: 161mm effective width of unlimited length lines Sprinklers: Toshiba 5PL Sprinklers Number: 24 or 36 (optional) Print colors: 4 or 6 color options Print height: 8CM Print Weight: precision nondestructive weight 50KG Print speed: 24 meters per minute, 18 m, 12 m 3 gear selection (about 230 square feet per hour) Ink system: UV inks (.... Black red yellow blue light red light blue.) Automatic cleaning system: automatic cleaning function (Intelligent positive and negative switching) Nozzle technology: Piezo ink jet printing Cartridge: CISS / Capacity 5000ml Supply voltage: Power 220V / 3600W Material handling: waistline, ceramics, wood, etc. Drying system: mercury lamp or LED lamp Color Control: ICC in line with international standards, with the curve Power Requirements: 220V Working platform: conveyor belt Interface: network transmission
| |
