Newest Heavy Duty AC-S Series Multi-jet Industrial UV Printer

Printing Size

Valid Width:1300mm  Unlimited Length

Print Head(s)

DONGZHI / JINGGONG

Print Colors

UV Curable Ink,4-7 Colors for Choice

Printing Height

100mm

Printing Weight

Non-destructive Accuracy weight:50KG

Printing Speed

Production Mode:300x1200dpi 98 sq/hr

Ink System

UV Curable Ink(C,M,Y,K,LC,LM)

Automatically Cleaning System

Automatic Cleaning Function(Intelligent positive pressure and Negative pressure)

Print Head Technology

Piezo inkjet printing ink

Ink Cartridge

Continuous Ink offering/Capacity: 2000ml

Power Supply

220V/3500W,50HZ/60HZ

Applied Materials

Ceramic, Acrylic, Wood,Bamboo, Tempo, Craft, Painting, Glass, Crystal,Mental,Leather,PVC,ABS etc.

Curing System

LED Light Curing (Mercury for choice)

Color Management

Admitted to International ICC standard,with Curve Line Function

Image Format

TIFF,JPEG,Postscript 3,EPS,PDF etc

Operating Platform

Conveying Belt

USB USB Connector:

USB 3.0 Connector

Operating Environment

Temperature:20-50℃ ,Humidity:40-60%,Dust-free room

Guide Rail

Square Linear Guide Rail

RIP Software Output

Main Top

N/W.

1850KG

Operating Platform

Vacuum Adsorption Platform (Alloy Aluminum Honecomb)

Equipment Size:

3427*4291*1692(mm)

Product Feature:Continuous running and the material delivering side can adjust the material direction automatically

Product Name: AC-S Series multi-jet industrial UV printer series

Features: continuous work uninterrupted feed end of the monolith with automatic function, automatic production line (see the actual operation of the video presentation)

Detailed device parameters

Print size: the effective width of 1300mm length Unlimited

Sprinklers: Dongzhi 5PL number of nozzles: 12-32 months (optional)

Print Color: 4-7 color options

Print height: 10CM

Print Weight: precision nondestructive weight 50KG

Print speed: Production mode: 300x1200dpi 98 sq / hr

Ink system: UV inks (.... Black red yellow blue light red light blue.)

Automatic cleaning system: automatic cleaning function (Intelligent positive and negative switching)

Nozzle technology: Piezo ink jet printing

Cartridge: CISS / Capacity 5000ml

Power supply voltage, power: 220V / 3600W

Material handling: ceramics, wood

Drying System: optional mercury lamp or LED lamp

Color Control: ICC in line with international standards, with the curve

Power Requirements: 220V

Work platform conveyor

Interface: USB 3.0 Universal Serial Interface
