Print Size |
Valid Width:2500mm Unlimited Length |
Print Head(s) |
CET4 636*2 6PL Print Head Quantity:12-32 for choice |
Print Colors |
4-7 colors for choice |
Print Height |
100mm |
Print Weight |
Non-destructive Accuracy weight:50KG |
Printing Speed |
Production Mode:300x1200dpi 108 sq/hr |
Ink System |
UV Curable ink(C,M,Y,K,LC,LM+W) |
Automatic Cleaning System |
Automatic Cleaning Function(Intelligent positive pressure and Negative pressure) |
Print Head Technology |
Piezo inkjet printing ink |
Ink Cartridge: |
Continuous ink flow (refillable while printing) /Capacity 2000ml |
Power Supply |
220V/3500W,50HZ/60HZ |
Applied Materials |
Ceramic,Acrylic,Wood,Craft,Painting,Glass,Crystal,Mental,Leather,PVC,ABS,etc |
Curing System |
LED light Curing ( Mercury for choice) |
Color Management |
Admitted to International ICC standard,with Curve Line Function |
Image Format |
TIFF,JPEG,Postscript 3,EPS,PDF etc |
Working Platform |
Conveying Belt |
USB USB Connector |
USB 3.0 USB Connector |
Operating Environment |
Temperature:20-50℃ ,Humidity:40-60%,Dust-free room |
RIP Software Output |
Maintop |
Guide Rail |
Square Linear Guide Rail |
Operating Platform |
Vacuum Adsorption Platform (Alloy Aluminum Honecomb) |
N/W. |
1700KG |
Equipment Size: |
4785*1883*1634(mm) |
|
Product Name: AC-W series of multi-jet printer industrial UV Features: front with auxiliary feed platform, the feed end of the monolith with automatic function, automatic production line Product details Print Dimensions: Effective width: 2500mm length Unlimited Sprinklers: Toshiba 5PL Sprinklers Number: 12-32 months (optional) Print Color: 4-7 color options Print height: 10CM Print Weight: precision nondestructive weight 50KG Print speed: Production mode: 300x1200dpi 108 square feet / hr Ink system: UV inks (.... Black red yellow blue light red light blue.) Automatic cleaning system: automatic cleaning function (Intelligent positive and negative switching) Nozzle technology: Piezo ink jet printing Cartridge: CISS / Capacity 5000ml Supply voltage: Power 220V / 3600W Material handling: ceramics, wood, glass Drying System: optional mercury lamp or LED lamp Color Control: ICC in line with international standards, with the curve Power Requirements: 220V Working platform: conveyor belt Interface: USB 3.0 Universal Serial Interface
| |
