Home > Manufacturing & Processing Machinery > Pharmaceutical Equipment & Machinery > Pharmaceutical Tablet Equipment > Lab Scale Tablet Press ,ZP17/ZP19 Rotary Tablet Press Machine

Lab Scale Tablet Press ,ZP17/ZP19 Rotary Tablet Press Machine

Huizhou Pingfang Trading Co., Ltd.

Lab Scale Tablet Press ,ZP17/ZP19 Rotary Tablet Press Machine photo-1

US$ 3,100 - 3,500 MOQ: 1 Unit

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Shanghai, China

Brand Name:

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port China( Mainland)

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Shanghai, China

Brand Name PF

Model Number ZP-17/19

Type Rotary Tablet Press

Production Capacity 25000-45000pc/h

Max. Pressure(KN) 40KN

Max. Tablet Thickness(mm) 6mm

Max. Tablet Diameter(mm) 13mm

Voltage 220V

Power(W) 2.2kw

Weight 500kg

Dimension(L*W*H) 880*750*1600mm

Certification CE/ISO

After-sales Service Provided Engineers available to service machinery overseas

ZP17/ZP19 Rotary Tablet Press Machine

1. technique parameter

Dies	19sets	17sets
Max. Pressure	40KN	50KN
Max. Dia. of Tablet	13mm	5.5-20mm
Max. Depth of Fill	15mm	15mm
Max. Thickness of Tablet	6mm	6mm
Turret Speed	20-40r/min	20-40r/min
Production Capacity	25000-45000pc/h	25000-45000pc/h
Motor	2.2KW 380V 50Hz	2.2KW 380V 50Hz
*Overall Size (LWH)*	*8807501600mm*	*8807501600mm*
Net Weight	500kg	500kg

2. Application:

This machine is not only suitable for pressing round tables from various kinds of granular materials but also different geometric shape tablets, specially for small-scale batch production. The turret carries 19(17) sets of punches and dies, so 19(17) tablets will be pressed for each revolution of the turret.

During operation, the speed of the turret rotation, the depth of the filling material and the thickness of the tablets can be adjusted. The mechanical buffer unit will prevent punches and apparatus from overload damage.

A powder suction unit is attached to take in the residual powder during operation, so that the blockage by the residual powder can be eliminated and the collected powder material can be reused.

3. Features:

1) The machine is compliance with the GMP requirement on the producting of pharmaceuticals.

2) The compression parts is entirely separeted from the driving mechanisms.

3) All spare parts to be in contact with the pharmaceuticals are made of stainless stell or the surface being treated specially for non-toxicity & corrosion proof.

4) The compression area is enclodsed with transparent organinc glass. To prevent contaminates, the compression area can be specially treated. All surfaces being smooth & easy to clean.

5) Machine speed, the depth of filling, the thickness of the tablet could be adjust.

6) The mechanical buffer unit will prevent punches and apparatus from overload damage.

4. Company introduce:

Our company is professional to do and export pharmaceutical machines, pharmaceutical packing material and others with a good reputation in the industry of China's pharmaceutical machinery

Our product include:

1). Kinds of drugs machinery: tablet press machine, capsule filling machine, blister packing machine, capsule filling machine, tablet coating machine, tablet/capsule counting production line, liquid filling machine, powder filling machine, liquid/powder/ cream packing machine and so on.

Welcome to scan our website:

2). Tester equipment in laboratory

3). Packing material: empty capsule, PVC, Aluminum foil, glass bottle, plastic bottle, laminated aluminum foil and so on

5. Certificate

6. Factory and exhibition photos:

Canton Fair show

Working room

7. Relation spare parts:

8. Other machines:
