Best Price Liquid Automatic Blister Packing Machine for Butter, Sauce and Ketchup
I. Introduction:
1. Main drive part adopts “R” Series Bevel Gear Type Motor from shanghai Omiter, chian drive splined shaft, main shaft drive forming, heat-sealing, batch number, cutter total 4 station cams to make up-down reciprocating motion. 4 station cams inner hole adopt spline type process, can make forming, batch number, cutter station to horizontal movement, suitable for different mould size adjustment. Main drive structure simple, durable, spline main shaft adopt 8 divide slot, diameter up to 64mm, steady, large torque, longer life.
2. Dragging parts adopt Taiwan (Delta) servo motor intelligent dragging, running steady and accurately. Can automatic adjust stroke, and make color-code track, adjustable stroke range is 40-200mm.
3. PVC and Alu foil transportation adopt sensor switch control, motor transport, avoid the conveying force when PVC and Alu foil first installed with big diameter, heavy weight, then become to small diameter, light weight, then to make synchronization more accurate, transport material more equal and steady.
4. Double layer working table use 1.5mm complete stainless steel, machine appearance all adopt 304SS, forming aluminium alloy, heat-sealing Cr12, cutter Cr13 chrome steel material, the contact parts with medicine all adopt innocuity material, conforms to GMP standard.
5. Cutter around and around can adjust, shorten mould adjustment time, reduce the material wastage.
6. Human Interface Operation, PLC control, stepless frequency inverter speed regulation, according to feeding state and blister sheet size, the speed around 6-36 time/min.
7. Adopt separate structure, easy to enter into clean workshop or through good ladder to enter into building workshop.
8. Adopt Register heating: shorten PVC heating time, effective protect PVC molecular structure, and save energy, when machine stop, the heating plate will open automatically to avoid more heating for PVC. Heating plate material: adopt stainless steel heating tube aluminium injection molding, and have antiseize coating.
II. Technical diameters:
Item | Unit | Parameter | |
Cutting speed | times/min | 6-25 | |
Power:3phases 4wires |
| 380V/50Hz | |
Adjustable stroke | mm | 40-200 | |
Max. forming area | mm×mm | 340×190 | |
Max. forming depth | mm | AL/PL 30 | |
Forming upper heat power | kW | 2.5 | |
Forming lower heat power | kW | 2.5 | |
Heat-sealing heat power | kW | 3 | |
Motor Power | kW | 2.2 | |
Air pump pressure | MPa | 0.5-0.6 | |
Air pump volume flux | m3/min | ≥0.36 | |
Packing material (H×W) | Medicine PVC | mm×mm | 0.25-0.40×350 |
PTP | mm×mm | 0.02×350 | |
Machine Dimension(L×W×H) | mm×mm×mm | 4000×850×1750 | |
Weight | kg | 2000 | |
Packaging Details: Export-standard and sea-worthy wooden case as following photos.
Delivery time: 15-45 working days normally
Free service: normal spare parts and quick worn parts will be delivered together with the main machine.
Huizhou Pingfang pharmaceutical machinery co. ltd. is a professional manufacturer and supplier for pharmaceutical machinery, pharmaceutical packing material company, who is standing firmly with a good reputation in the industry of China pharmaceutical machinery.
Our company focus on fabricating efficient and technically sound pharmaceutical machines that meets or exceed our customer’ expectations. Our vast product selection caters to numerous industries, worldwide. We are specializing in machinery including, pulverizes, mix, Granulate, tablet press machine, coating machine, soft capsules filling machine, hard capsules filling machine, ampoule filling and sealing machine, oral liquid filling production line, syrup machine, eyes drop filling machine, lyophilized powder production line, injectable vial powder filling production line, Ointment machine, Suppository machine, spray filling machine, pharmaceutical testing and experiment instrument, traditional Chinese medicine machine and packing materials. The packing materials including pharmaceutical PVC, PTP aluminum film, hard aluminum, vial, stopper, aluminum stopper, ampoule, glass, capsule, packing strap of suppository physic. Meanwhile, we can undertake turn key projects for conceptual design, process design, water treatment solutions, clean-room design, etc.
Because we stick to offer the high quality and competitive price to our customer, our machines have been exported many countries of world such as Singapore, Vietnam, Malaysia, Thailand , Bangladesh, USA, Russia, Pakistan, Nigeria, Chile, Germany, Denmark, Bolivia, Peru, Mexico, South Africa, Iran, Argentina, Canada, Australia, India, Kazakhstan, Turkey, Egypt, Brazil, Syria, Yemen and more. In order to offer the best quality, we manufacture our products in accordance with international standards, such as FDA, GMP, CGMP. We also be approved by CE, ISO certificate, too.
Our Customers:
Our Certificates:
Q1: What information should I let you know if I want to get quotation?
A: -the size of products (Length*Width*Height)
-the material
-if it is possible, please provide us the pictures or the design drawings, our designer will analyze your samples and give you exact details.
Q2: Is there MOQ for our machine?
A: 1 set is acceptable. Of course, if you order more, it will be fine and its price will be more competitive.
Q3: Do you have manual or operation video for us to know more about the machine?
A: Yes, of course. Please email us and ask for it. We will send you soon.
Q4: When can I get the price?
A: We usually quote within 24 hours after getting your inquiry. If you are urgent to get the price, please call us or tell us in your email. We will regard your inquiry priority.
Q5: How does your factory regard quality control?
A: Quality is priority. It’s the basement of company’s development. From the beginning of opening company, we especially focus on quality job. Our pharmaceutical equipment have passed the GMP model patents and invention patents issued by State Patent Office of China.
Pre-sale:
According to customer’s needs guide customers t configure the most appropriate device models. According to customer’s special requirements and working site provide list of equipment, equipment layout.
Dur-sale:
Inspect the product seriously before out of the factory. Invite customer for commissioning in the spot and raising the objection. Organize to delivery according to the contract.
After-sale:
Company can send technical data for guiding to install and debug the machine. After a year, we can instruct you how to maintain the machine, and spare parts are provided with the best price. We also can provide 24-hour telephone or message service.
