BJ-04MAX Steel Wire Rope Stripper Machine
Production Induction:
This type of machine is a high-technic product developed by ourselves.The minimum stripping length is 1mm and the maximum is 10m.It can be widely used for the process of wire stripping,the industries such as :control cabinet equipment,the factory of wire lock,electronics industry,electronic power,injection molding machine,electric power tool,the automobile accessories industry,electrical machine,electric appliance,air-condition,washing machine,electronic instrument,toy,lamps and lanterns,transformer.It is the lowest price of the same kind of wire- stripping machine and running stablely,easy to operate,it is widely welcomed by the most of our customers.It is your best choice.
Technical Parameter:
Model | BJ-04MAX |
Display Way | Digital Display |
Power Supply | AC 220V/50Hz |
Power | 180W |
Cutting length | 1mm-50mm-10m |
Cutting Tolerance | ±(0.2+0.0002xL)mm L=length |
Stripping Length(head) | 0-25mm |
Stripping Length(end) | 0-15mm |
Exhausted line way | full strip both ends, half off, short strip, middle strip |
Fitting Wire Section Acreage | 0.1mm2-25mm2 |
Fitting Wire Materiatal | PVC,Teflon glass wire, Steel wire |
Speed | 8000-3000 pcs/h |
Blade Material | Import tungsten steel |
Wire Diameter Adjustment | Automation |
Stripping Wire Quality | advance |
Rollers press adjustment | Yes |
Stripping Press | Auto sise |
Operation Video
/watch?v=IcHe1x-N5xs
We Provide
- Best products and factory price.
- On-time delivery and the shortest delivery time.
- 1-year warranty. If our products cannot function properly within 12 months, we'll offer spare parts for free; and you need to pay for the delivery.
- OEM and customized service.
- User manuals will go with relative machines.
Service
- QC: All products will be checked before delivery.
- Compensation: If any unqualified product is found, we'll pay the compensation or send new qualified products to customers.
- Maintenance & Repair: In case of any maintenance or repair need, we'll help to find out the problem and offer relative guidance.
- Operation Guidance: If you have any problem with operation, please feel free to contact us.
....
