BJ-02K Flat Cable Stripping Machine
Wire diameter: 0.1-4.0mm2
Wire Size: AWG22-28
Cutting Length: 0.1-6000mm(Determined on wire materials)
Cutting Tolerance: ±(0.2+0.0002×L)mm (L=Cutting Length)
The max width: 12P(mm2) / 20mm
Processing Capacity: 8000-3000wires/hour
Fitting Wire Material: flat cable, data cable, flat wire
We manufacture wire stripping machine, wire stripper, tape cutting machine, tube cutting machine, label cutting machine, automatic tape & label dispenser, automatic label rewinder,etc. High quality & low price!
Power Supply |
220V / 50/60Hz |
Power Rating |
280W |
Wire diameter |
0.1-4.0mm2 |
Wire Size |
AWG22-28 |
Cutting Length |
0.1-6000mm(Determined on wire materials) |
Cutting Tolerance |
±(0.2+0.0002×L)mm (L=Cutting Length) |
The max width |
12P(mm2) / 20mm |
Processing Capacity |
8000-3000wires/hour |
Fitting Wire Material |
flat cable, data cable, flat wire |
Drive Way |
Four Wheel Drive At The Same Time |
Stripping Length |
head 0-35mm, end 0-15mm |
Wire Diameter Adjustment |
Automation |
Rollers Press Adjustment |
Setup |
Stripping Press |
Auto Rise |
Wire Stripping Quality |
Advance |
Parameter Memory Function |
None |
Blade Material |
Sungsten Steel |
Mearsurement |
420*390*280mm |
Net Weight |
36Kg |
Remark |
Stretcher is Selective |
BJ-02K Flat Cable Stripping Machine
We Provide
- Best products and factory price.
- On-time delivery and the shortest delivery time.
- 1-year warranty. If our products cannot function properly within 12 months, we'll offer spare parts for free; and you need to pay for the delivery.
- OEM and customized service.
- User manuals will go with relative machines.
Service
- QC: All products will be checked before delivery.
- Compensation: If any unqualified product is found, we'll pay the compensation or send new qualified products to customers.
- Maintenance & Repair: In case of any maintenance or repair need, we'll help to find out the problem and offer relative guidance.
- Operation Guidance: If you have any problem with operation, please feel free to contact us.
Related Wire stripping machines
Model Number |
BJ-02B |
BJ-02D |
BJ-02F |
BJ-02MAX |
Wire size |
0.1~2.5 mm2 |
0.1- 4.5mm2 |
0.2 - 8.0 mm2 |
0.2- 16mm2 |
Conduit diameter |
Φ6 |
Φ6 |
Φ10 |
Φ13 |
Wire Gauge Range |
AWG16 - AWG32 |
AWG12 - AWG32 |
AWG8 - AWG32 |
AWG5-AWG30# |
Drive Mode |
Four-wheel drive |
Four-wheel drive |
Four-wheel drive |
Four-wheel drive |
Weight |
35kg |
35kg |
35kg |
35kg |
