Product Description
Function:
Meter,wire cutting,winding displacement /irregular,winding,binding
Features:
1. High accuracy for meter, with complete function, Meter, winding displacement, winding and binding wire
2. High winding speed
3. Available different wire diameter
Equipment parameter:
* Winding coils:1-999coils
* Winding speed:1-4coils/sec
* Available wire diameter: 2-7mm or 6-10mm, only can choose one spec
* Winding wire diameter(inside diameter):60-190mm, we will match two specs different size winding axles, it is nonadjustable.
* Winding wire diameter(outside diameter):less than260mm
* Width of winding displacement:10-70mm
* Available wire shape: round,flat wire(doubling etc.)
* Binding diameter:5-28mm or 15-40mm.only can choose one spec.
* Available belt length:75-135mm or 120-180mm ,only can choose one spec.
* Twisting belt coils:2-8 coils. It is adjustable
* Dimesion:1100*1150*430mm
* Weight: around 75KG
* Voltage: AC220V±10% 50Hz/60Hz
* Power:<1000w
* Whether trim winding displacement or not: trim
* The meter length tolerance: less than 5 m tolerance is ±1cm
5-10 m tolerance is ±1.5-2cm
10-20 m tolerance is ±3-3.5cm
20-30 m tolerance is ±4-5cm
Operation Video:
Wire Winding And Measuring Machine BJ-SJPZ
Payment & Delivery
* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.
We Provide
* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.
Service
* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us.
We Provide
- Best products and factory price.
- On-time delivery and the shortest delivery time.
- 1-year warranty. If our products cannot function properly within 12 months, we'll offer spare parts for free; and you need to pay for the delivery.
- OEM and customized service.
- User manuals will go with relative machines.
Service
- QC: All products will be checked before delivery.
- Compensation: If any unqualified product is found, we'll pay the compensation or send new qualified products to customers.
- Maintenance & Repair: In case of any maintenance or repair need, we'll help to find out the problem and offer relative guidance.
- Operation Guidance: If you have any problem with operation, please feel free to contact us.
....
