Product Description
Features:
1. High accuracy for meter
2. Trim winding displacement
3. Available different wire diameter
Equipment parameter:
Winding coils:1-999coils
Winding speed:1-4coils/sec
Available wire diameter: 2-7mm or 6-10mm ,only can choose one spec.
Winding wire diameter (inside diameter):60-190mm, we will match two specs different size winding axles, it is nonadjustable.
Winding wire diameter (outside diameter): less than260mm
Width of winding displacement: 10-70mm
Available wire shape: Round,flat wire etc.
Dimesion:1100*1150*430mm
Weight: Around 55KG
Voltage: AC220V±10% 50Hz/60Hz
Rating:<1000w
Whether trim winding displacement or not: trim
The meter length tolerance: less than 5 m tolerance is ±1cm
5-10 m tolerance is ±1.5-2cm
10-20 m tolerance is ±3-3.5cm
20-30 m tolerance is ±3-3.5cm
Remark : The quotation not include the price of pay-off machine, the price of pay-off machine based on the wire degree of thickness ,weight. And for the round wire which diameter less than 4mm, also the wire material is soft, we suggest not use the pay-off machine
Operation Video:
Meter Winding machine BJ-SJPQ
