Wire Winding And Measuring Machine BJ-SJPQZ
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Meter Winding Machine BJ-SJPQ
-
Hot Selling Cheap Plastic Twist Tie Machine
-
Automatic Wire Binding Machine/Cable Bundling Machine/Cable Bundler BJ-3050
-
Automatic Wire Binding Machine/Cable Bundling Machine/Cable Bundler BJ-1020
-
Automatic Wire Rewinder /Cable Bundling Machine/Cable Bundler BW-501
-
New Product Twisting Tying Wrapping Machine Tie Machine Wrap Machine
Product Details
| Place of Origin | Jiangsu, China | Brand Name | BOJIN | |
| Model Number | BJ-SJPQZ | Usage | Other, Peeling |
Product Description
Product Description
Function:
Meter,wire cutting,winding displacement /trimming,winding,binding
Features:
1. High accuracy for meter, with complete function, Meter, winding displacement, winding and binding wire
2. Trim winding displacement
3. Available different wire diameter
Equipment parameter:
* Winding coils:1-999coils
* Winding speed:1-4coils/sec
* Available wire diameter: 2-7mm or6-10mm, only can choose one spec.
* Winding wire diameter(inside diameter):60-190mm, we will match two specs different size winding axles, it is nonadjustable.
* Winding wire diameter(outside diameter):less than260mm
* Width of winding displacement:10-70mm
* Available wire shape: round,flat wire(doubling etc.)
* Binding diameter:5-28mm or 15-40mm. only can choose one spec.
* Available belt length:75-135mm or 120-180mm ,only can choose one spec.
* Twisting belt coils:2-8 coils. It is adjustable
* Dimesion:1100*1150*430mm
* Weight: around 75KG
* Voltage: AC220V±10% 50Hz/60Hz
* Power:<1000w
* Whether trim winding displacement or not: trim
* The meter length tolerance: less than 5 m tolerance is ±1cm
5-10 m tolerance is ±1.5-2cm
10-20 m tolerance is ±3-3.5cm
20-30 m tolerance is ±4-5cm
Remark:
The quotation not include the price of pay-off machine, the price of pay-off machine based on the wire degree of thickness ,weight. And for the round wire which diameter less than 4mm, also the wire material is soft, we suggest not use the pay-off machine.
Operation Video:
Wire Winding And Measuring Machine BJ-SJPQZ
