Help CenterMeter Winding Machine BJ-SJP
Related Products
-
BJ-508 Cable Twist Packing MachineNegotiableMOQ: 1 Unit -
BJ-507 Cable Twist Packing MachineNegotiableMOQ: 1 Unit
-
Automatic Wire Binding Machine/Cable Bundling Machine/Cable Bundler BJ-08DXUS$ 3,100 - 4,000MOQ: 1 Unit
-
Wire Winding And Measuring Machine BJ-SJPZNegotiableMOQ: 1 Unit
-
Wire Winding And Measuring Machine BJ-SJPQZNegotiableMOQ: 1 Unit
Product Description
Function:
Meter,wire cutting,winding displacement /irregular,winding
Features:
1. High accuracy for meter
2. High winding speed
3. Available wire diameter is wider
Wire Pay-off: need make an extra quotation based on degree of wire thickness , weight
Equipment parameter:
* Winding coils:1-999coils
* Winding speed:1-4coils/sec
* Available wire diameter: 2-7mm or 6-10mm only can choose one spec
* Winding wire diameter(inside diameter):80-250mm, it is adjustable.
* Winding wire diameter(outside diameter):less than300mm
* Width of winding displacement:10-70mm
* Available wire shape: round,flat wire(doubling etc.)
* Dimesion:1100*1150*430mm
* Weight: around 55KG
* Voltage: AC220V±10% 50Hz/60Hz
* Power:<1000w
* Whether trim winding displacement or not: Irregular
* The meter length tolerance: less than 5 m tolerance is ±1cm
5-10 m tolerance is ±1.5-2cm
10-20 m tolerance is ±3-3.5cm
20-30 m tolerance is ±4-5cm
Remark:
The quotation not include the price of pay-off machine, the price of pay-off machine based on the wire degree of thickness ,weight. And for the round wire which diameter less than 4mm, also the wire material is soft, we suggest not use the pay-off machine.
Operation Video:
Meter Winding Machine BJ-SJP
Payment & Delivery
* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.
