YN 27C/YN27T Gasoline Rock Drill
USD $200 - $300
/ Unit
1 Unit(Min.Order)
- 10000 Unit / Units per Month
- Ningbo
- T/T Credit Card PayPal
You May Like
-
China Xy-200 Water Well Drill Rig Machine for Soil and Rock Drilling
-
100 Meters Xy-1A Water Well Drilling Rig Machine Equipment
-
HY-50H Small Domestic Hydraulic Water Well Drilling Rig of China
-
50m Depth Core Drilling Rig Portable Diamond in Mountain
-
TSP core bit, BQ NQ HQ PQ core drill bits, HWL, wireline core barrels, diamond coring bits, hard formation, deep hole rock core recovery
-
1.5M 3M inner tube assembly, wireline core barrels, head assembly, impregnated diamond drilling, hard formation coring, deep hole rock core recovery
Product Details
| Condition: | New | Type: | Core Drilling Rig | Power Type: | Gasoline |
| Place of Origin: | Fujian, China | Brand Name: | GM | Model Number: | YN 27C/YN27T Gasoline Rock Drill |
| Usage: | Coal | Weight: | 27 kg | Certification: | CE |
Product Description
Specifications
Gasoline Rock DrillIt is widely used in mine, road construction, quarrying, national defense works, etc.
YN 27C/YN27T Gasoline Rock Drill
Combustion Rock Drill Type Combustion Rock Drill Type Combustion Rock Drill Type Combustion Rock Drill Type Combustion Rock Drill Type
The Internal Combustion Rock Drill Type YN 27C has functions of drilling hole, cleavage, bruising, tamping and chiseling. It is widely used in mine, road construction, quarrying, national defense works, etc.
TECHNICAL SPECIFICATIONS | |
Weight of main machine | 27 kg |
Type of carburetor | Hand needle valve, no floating type |
Ignition system | Controllable silicon contactless system |
Displacement of engine piston | 185 cm3 |
Rotating speed of engine | ≥2450 r/min |
Rotating speed of drill rod | ≥200 r/min |
End of drill rod dimensions | Hexagonal 22x108 mm |
Max drilling depth | 6 m |
Tank capacity | 1.14 L |
Drilling speed | ≥250mm/min |
Mixture ratio of gasoline and lubricating oil(in volumes) | 12:1 |
Clearance of spark plug | 0.5~0.7 mm |
