Y20LY Hand-hold and Air Leg Rock Drill

Y20LY Hand-hold and Air Leg Rock Drill thumbnail-1
Y20LY Hand-hold and Air Leg Rock Drill thumbnail-2
Y20LY Hand-hold and Air Leg Rock Drill thumbnail-3
Y20LY Hand-hold and Air Leg Rock Drill thumbnail-4
Y20LY Hand-hold and Air Leg Rock Drill thumbnail-5
Y20LY Hand-hold and Air Leg Rock Drill thumbnail-6
Y20LY Hand-hold and Air Leg Rock Drill photo-1
Y20LY Hand-hold and Air Leg Rock Drill photo-2
Y20LY Hand-hold and Air Leg Rock Drill photo-3
Y20LY Hand-hold and Air Leg Rock Drill photo-4
Y20LY Hand-hold and Air Leg Rock Drill photo-5
Y20LY Hand-hold and Air Leg Rock Drill photo-6
US$ 150 - 250 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
GM
Model Number:
Y20LY Hand-hold and Air-leg Rock Drill
Contact Supplier Request Quote Chat Now
Fuzhou Golden Moral Imp & Exp Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name GM
Model Number Y20LY Hand-hold and Air-leg Rock Drill
Type Air Drill
Average Air Consumption 4 Cfm
Maximum Torque Adjustable
No-Load Speed 000rpm
Product Description

 Y20LY Hand-hold and Air leg Rock Drill

Y20LY Hand-hold and Air-leg Rock Drill

 Instruction

The rock drill is a kind of light rock drill machinery. It can perform both dry and wet drilling under medium hard or hard rock(f=8-18).(the diameter of blast hole is 34mm-40mm, the depth of hole is 3m)

This machine can drill downward with hand toward horizontal or acclive,when it is matched with air-leg model FT100, it is suitable for drilling works in various mines,quarries,capital construction of farmland, blasting for constructing roads in mountain areas and other projects.

This machine has transparent surface of FY200B lubricator to guarantee good lubrication,but also can be matched with model FT100 air leg.

Specification

Weight                                                      ≈18kg

Length                                                    ≈609mm

Cylinder dia.                                                  60mm

Piston stroke                                                  50mm

Air pressure                                               0.4Mpa

Impact frequency                                            ≥30Hz

Air pipe inner dia                                        16 or or19mm

Water pipe inner dia                                              8mm

Air consumption                                           ≤25 L/S

Shank dimension                                    22×108mm±1mm

Bit dimension                                             34- 40mm

FT100type air leg

Length                                                     1312mm

Piston stroke                                                  810mm

Cylinder dia                                                   52mm

Weight                                                       ≈11kg
