Y018 Hand Held Rock Drill,cheapest Price

Y018 Hand Held Rock Drill,cheapest Price thumbnail-1
Y018 Hand Held Rock Drill,cheapest Price thumbnail-2
Y018 Hand Held Rock Drill,cheapest Price thumbnail-3
Y018 Hand Held Rock Drill,cheapest Price thumbnail-4
Y018 Hand Held Rock Drill,cheapest Price photo-1
Y018 Hand Held Rock Drill,cheapest Price photo-2
Y018 Hand Held Rock Drill,cheapest Price photo-3
Y018 Hand Held Rock Drill,cheapest Price photo-4
US$ 1 - 100 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
GM
Model Number:
YO18
Contact Supplier Request Quote Chat Now
Fuzhou Golden Moral Imp & Exp Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name GM
Model Number YO18
Type Air Drill
Average Air Consumption 22.6L/S
No-Load Speed 000rpm

Y018 Hand held Rock Drill,cheapest price:

   The rock drill is used for rock drilling, blasting holes and other drilling works in the quarries, small coal mines and other constructions.  It’s suitable for drilling of horizontal or inclined holes on the medium-hard and hard rock. When it’s matched with air leg Model FT100, it can blast holes from different directions and angles.Blast hole diameter is between 36mm and 42mm. with an efficient depth from 1.5m to 2m.It’s recommended to be matched with Model py-1.2/0.39 air compressor which is powered by Model RS1100 diesel engine. Other suitable air compressors can also be matched with this rock drill..

Weight                                         18kg

Overall length                                 550mm

Cylinder dia.                                     58mm

Piston stroke                                      45mm

Air pipe inner dia.                                 19mm

Water pipe inner dia.                                8mm

Shank dimensions                             22×108mm

Water pressure                             3.9-5.9×105Pa

Air pressure                                 ≤at 3.9 MPa

Air consumption(at3.9×105 Pa)             <1.2m3/min(22.6L/S)

Average speed (at 3.9×105Pa )                      80mm

Impact energy(at4.9×105Pa )                           24.5J(31Hz)

Torque(at4.9×105Pa )                           7.85N·m

Airconsumption(at4.9×105Pa )              ≤1.35m3/min

Average speed(at4.9×105Pa )                       120mm

 FY200 oil lubricator

Weight                                           ≤1.2kg

Oil capacity                                       200mm

FT100 air leg

Weight                                             11kg

Propulsion stroke                                   810mm

Cylinder dia.                                       52mm

Length                                          1312mm
