Miner Machine Shaking Table1) Big steel intensity;
2) Low water-absorptivity,anti-chemical corrosion acid;
3) High efficienc
miner machine Shaking Table
Shaking Table Shaking Table Shaking Table Shaking Table Shaking Table Shaking Table Shaking Table
Introduction:
Shaking table (shake table) is one of the important dressing equipment depending on the gravity. It is widely used in selection of Tin, tungsten, gold, silver, lead, zinc, tantalum, niobium, iron, manganese, ferrotitanium and coal.
The raw materials on the shaking table are with mixed densities, the suspending particles of the materials will leak down from the shaking table for its bearing the larger force. When the shaking table works, the raw materials on the table will tumbling and sliding with the shaking table. The different speed of the particles will lead the table expanding, then the particles with smaller size will screening out. The raw mineral materials will be selecting by adjusting the speed of the table.
Features of Shaking Table:
1) Big steel intensity;
2) Low water-absorptivity,anti-chemical corrosion acid;
3) High efficiency.
Technical Parameters of Shaking Table:
Model |
L-S type(6-S) |
Clean water(t/h) |
0.4-0.8 |
Stroke(mm) |
10-30 |
Table size (mm) |
1520*1825*4500 |
Frequency(time/min) |
240-360 |
Motor(kw) |
1.1 |
Horizontal obliquity(o) |
0-8 |
Capacity(t/h) |
0.5-1.2 |
Sorting size(mm) |
2-0.074 |
Weight (kg) |
1012 |
Feeding thickness(%) |
15-30 |
Dimension(mm) |
5454*1825*1242 |
Introducción:
Sacudir tabla (tabla sacudida) es uno de los equipos apósito importante en función de la gravedad. Es ampliamente utilizado en la selección de estaño, tungsteno, oro, plata, plomo, zinc, tántalo, niobio, hierro, manganeso, ferrotitanio y carbón.
Las materias primas de la mesa vibradora son con densidades mixtas, las partículas en suspensión de los materiales que se filtran por debajo de la mesa vibratoria de su relación a la fuerza mayor. Cuando funciona la mesa vibratoria, las materias primas en la tabla se volteo y deslizante con la mesa vibradora. La diferente velocidad de las partículas conducirá la mesa en expansión, a continuación, las partículas de menor tamaño serán descartar a. Las materias primas minerales se seleccionan mediante el ajuste de la velocidad de la
