ZL15 Mini Wheel Loader

ZL15 Mini Wheel Loader photo-1
ZL15 Mini Wheel Loader photo-2
ZL15 Mini Wheel Loader photo-3
ZL15 Mini Wheel Loader photo-4
ZL15 Mini Wheel Loader photo-5
ZL15 Mini Wheel Loader photo-6
US$ 1 - 5,583 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
GM
Model Number:
ZL15
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Brand Name GM
Model Number ZL15
Place of Origin Fujian, China
Type Mini Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 4760x1680x2550mm
Rated Load 3600kg
Certification 1500KG
Warranty One Year
After-sales Service Provided Overseas third-party support available

ZL15:

Performance Characteristics:

1 With motor of famous brand, with driving power, economizes on energy and protect the  environment

2 Novel appearance and model, capacious operator cabin, favorable eyeshot

3 Convenient back cover for repairing, centralized lubricating system, which is convenient to maintain and upkeep

4 Rotary Oil Tank, convenient to add oil

5 Ascendant performance of complete appliance, with extraordinary operation efficiency

6 With which many kinds of optional components can be matched to meet requirements of different users.

specification

Rated load(kg)

1500

Max. Dump height(mm)

2750

Rated bucket capacity(m³)

0.7

Overall weight (kg)

3600

Bucket indicator

yes

L*W*H(mm)

4760*1680*2550

Max.breakout force(KN)

43

Engine

Model

Xinchai498(EUROIII)

Type

IN-line arrangement, water cooling, four- stroke

Rated power(kw)

47

Rated speed(r/min)

2550

Transmission system

Model of torque converter

YJ240

Type

Single-phase single-stage radial-inward turbine triplex

Gearbox type

Fixed-spindle power shift

Gear shift

2 gears ahead, 2 gear astern

Hydraulic system

Distribution of work valve

ZL20B

Working pump

CBGj1045,CBGq1018

Steering system

Type

Articulated hydraulic steering

Max.turning angle

27±1°

Min. Turning radius(mm)

3000

Brake system

Brake type

Oil brake(Vacuum booster)

Tyres

Standard tyres

12-16.5

Optional wide tyres

14-17.5





ZL15 Mini wheel loaderZL15 Mini wheel loader
