Industry Antistatic Polyester Pleated Dust Collector Air Filter Cartridge p191920
I. Polyester fiber air filter cartridge
It is made of imported polyester fiber filter material and used in the fields such as powder spraying, sandblasting, paint, wood, and cement.
II. Coated polyester air filter cartridge
It is made of imported PTFE coated polyester filter material and it has a long service life, which can up to 2 to 3 years in common operating conditions. It is applied in the filtration in such areas like the weld dust, shot peening casting, pharmacy, cement, tobacco, textile (e.g. yarn for prevention of coal ash) industries.
III. Antistatic filter cartridge
The filter cartridge is treated with anti-static aluminum coating, which is covering the surface of the filter material with a very thin conductive aluminum coating with air permeable, to avoid electrostatic fire. It is used for dust removal in the explosion-proof working conditions.
IV. Water-proof and oil-proof filter cartridge
The filter cartridge is treated by covering the filter material with a layer of fluorine resin to prevent water, oil and pollution. It is used for filtering wet, greasy or high-concentration dust. It has a better effect on large-size dry dust.
V. Wood pulp fiber air filter cartridge
It uses air filtration composite filter paper which applied in the filtrating fields such as gas turbine, compressor, sandblasting, tobacco, fly ash and dust removal.
Common Specifications of dust collector filter cartridge
| Model | Outside diameter of the upper-lid | Inside diameter of the upper-lid | Outside diameter of the bottom lid | Diameter of the installation holes | Height | ||
| LFK 3266 | Φ324 | Φ213 | Φ324 | Φ14 | 660 | ||
| LFK 3275 | Φ324 | Φ213 | Φ324 | Φ14 | 750 | ||
| LFK 32100 | Φ324 | Φ213 | Φ324 | Φ14 | 1000 | ||
| LFK 3566 | Φ352 | Φ241 | Φ352 | Φ16 | 660 | ||
| LFK 3575 | Φ352 | Φ241 | Φ352 | Φ16 | 750 | ||
| LFK 35100 | Φ352 | Φ241 | Φ352 | Φ16 | 1000 | ||
Donaldson Filter Part number we have :
P190818
P034584-016-436
2626913-000-440
2625115?
P031791-016-436?
P191920-016-436
P191920
LF-660*324
2625115
P19-1037
?P031256-016-340
P031791-016-436
?P951280-000-710
P034303-016-436
P951281-000-480
P03-0254
P19-177?
P19-1178
2625175
325 x 1000 mm
P031791-016-436,
P191889
p034077
P19-1281
0850-R025-W/HC
P191889-016-436
P190848
P191889
p191280
P785590
P785401
2627283-000-440
P190818
P165006
P566336
p190613 016 340
P173915
P173916
P550687
P551604
ECC125004
P142807
P191558-016-340
2625173-000-440
P191523-016-436
P190906-016-436
P520433-016-340
P030902-016-436
P034584 ?016142
P033137-016-340
P032221-016-433
P527081 ?000111
P034081-016-436
P164158-016-190
P191564-016-340
P033786 ?000111
P199413-016-431
P030915 ?000111
P145891-016-436
P521420-016-436
P031792 ?016142
P190884-016-426
P199474-016-436
P148646-016-340
P190837-016-426
P034597
P165659
2626913-000-440
2627283-000-440
P034303
P034310
P034584
P034308
P191889
P191920
P199474
P030627
262-5112?
262-5152
262-5115
262-6302
262-5116
262-5117
262-5118
2625175
2626582
p191920
Our products through the following test:
ISO 2941 Collapse & Burst Resistant
ISO 2942 Material Compatibility with Fluids
ISO 2943 Material Compatibility with Fluids
ISO 3724 Flow Fatigue Characteristics
ISO 3968 Pressure Drop vs. Flow Rate
ISO 16889 Multi-pass Performance Testing
Company profile
Xinxiang Lifeierte Filter Corp.,Ltd (Stock code:837936)is specialized in manufacture of filters ,filter equipment,and environment system . Located in Xinxiang -the center of Filtration in China.Lefilter has superior R & D team, professional technical team,experienced overseas sales team and perfect after-sales service system.We Lefilter people will try our best to satisfy customers' requirements.The develop philosophy of LEFILTER is "To purify environment,To serve society,To manage faithfully and To oyrsye excellence"!What's more,there're advanced production line,test machine and R & D department.They also obtained certification like ISO9001, IQNet & CQM,SGS,CNEX etc.
