5T Wheel Loader SX956 WHEEL LOADER SX956 FRONT WHEEL LOADER

Items

Specifications

Items

Specifications

Rated capacity

3.5 cubic metre

Transmission system

Gear box and torque-converter, the whole unit

Rated weight

5000kg

Torque-converter model

SWYJ315-6

Operating weight

16500kg

Type

Double-turbine

Automatic leveling ability

Yes

Transmission box type

Full power shift, planetary power chang-shift type

Static tilting load

110KN

Number of gear shift

2forward and 1 reverse

Max breakout force

175KN

Max travel speed

36km/h

Max drawing force

145KN

Front and rear axle

Max grade ability

30°

Main reducer type

Single stage spiral reduction

Max.dump height

3300mm

Final reducer

Single stage planetary

Max.dump reach

1285mm

Tire

Min.ground clearance

410mm

Size

23.5-25

Wheel base

3200mm

Front wheel air pressure

343kpa

Tread

2250mm

Rear wheel pressure

304kpa

Lifting time

6.5s(full load )

Steering system

Total cycle time(lifting, dumping, lowering)

12s(full load)

Type

Coaxes flow-amplified,
pressure-compensated

Overall dimensions (l×w×h)mm

8110×3070×3400

steering angle

35°±1 respectively left/right

Engine

Wei chai engine (Chinese famous brand)

Min turning radius

6288mm(outside of rear wheel)

Model

WD615G.20

Hydraulic system

Type

In line, water cooled, four stroke, direct inject

Type

Twin pumps merging

Rated power

162KW

Distribution valve

DF32.2

Rated rotation speed

2200r/min

Gear pump

GBGj3100

Min oil consumption ratio

214g/kw.h

Brake system

Service brake

Air assisted oil disc type four-wheel brake

Parking brake

Air off control inner expand hoof

Fuel tank capacity

125L
