Specifications
Wheel Loader SX938Rated load:3000 kg
Brief introduction of our company:
We, Shandong Senxin Construction Machinery Group is the professional supplier of the heavy equipment and related spare parts.
We supply the wheel loader, excavator, road roller, backhoe loader, bulldozer and motor grader, brand including SDLG, XCMG, SHANTUI, LIUGONG,SENX.
Our advantage
1. High quality at reasonable price
2. Prompt delivery
3. Rich experience
4. Quick supply of spare parts
5. Professional shipping &package
6. Professional after-sales service
>> Professional: Proven technique can prove stable products,brought you smooth experience in importing.
>> High efficiency,we can handle your requiry swiftly,and will supply good following-service in spare parts for wheel loader.
>> Experienced:18 years export experience can make us skilled the clearance documents for you in short time
Information of SX935 WHEEL LOADER
Items | Specifications | Items | Specifications |
Rated capacity | 1.7m3 | Transmission system | Gear box separated from torque-converter |
Rated weight | 3500kg | Torque-converter model | YJ315x |
Operating weight | 9800kg | Type | Three-element, single stage |
Automatic leveling ability | Yes | Transmission box type | Full power shift, countershaft type |
Static tilting load | 58.8KN | Number of gear shift | 4 forward and 2 reverse |
Max breakout force | 120KN | Max travel speed | 36km/h |
Max drawing force | 90KN | Front and rear axle |
|
grade ability | 30° | Main reducer type | Single stage spiral reduction |
Max.dump height | 3050mm | Final reducer | Single stage planetary |
Max.dump reach | 1105mm | Tire |
|
Min.ground clearance | 410mm | Size | 17.5-25 |
Wheel base | 2600mm | Front wheel air pressure | 343kpa |
Tread | 1800mm | Rear wheel air pressure | 294kpa |
Height with bucket at full raise | 4870mm | Steering system | Fully hydraulic steering |
Lifting time | 5.5s(full load ) | steering angle | 35°±,135°±1 respectively left/right |
Total cycle time(lifting, dumping, lowering) | 9.67s(full load) | Min turning radius | 5160mm
|
Overall dimensions (l×w×h)mm | 6990×2420×3000mm | Hydraulic system |
|
Engine | Yuchai engine shares co.,ltd | Distribution valve | DF25.2C |
Model | YC6B125-T10 | Gear pump | GBGV2100 |
Type | In line, water cooled, four stroke, direct.inject | Brake system |
|
Rated power | 92KW | Service brake | Air assisted oil disc type four-wheel brake |
Rated rotation speed | 2200r/min | Parking brake | Soft axis, cable control |
Min oil consumption | 235g/kw.h | Fuel tank capacity | 125L |
Wheel Loader 3.0T SX938 mini/small wheel loader made in china
Shandong Senxin Construction Machinery Group.
Add:Room1001, Jiarui Building, Linyi City, Shandong Province, China.
Tel: 0086-539-8180952 Fax:0086-539-8180951
----------HAND IN SENXIN, ONE STEP AHEAD----------
Thank you for visiting our products & Looking forward to hearing from you!
