G9200 China cheap motor grader G9200 motor grader good quality good price
| G9200 is a product of high speed, high efficiency, high accuracy and multiple purposes developed on the basis of advanced technology of VOLVO, can be used for ground leveling and grooving, scraping slope, bulldozing, ploughing snow, loosening, compacting, material arrangement and mixing works, and is widely applied in construction operating condition of road, airport, defence engineering, mine construction, road construction, water conservancy construction and farmland improvement and so on. | |
| It is equipped with dual-cylinder driven tray-type working device of advanced VOLVO technology and domestic industrial originated dual rotatory cylinder and rotatory valve structure which is of large drive power and can rotate with load. | |
| Electrical system of the entire machine has centralized control, three-stage alarm electronic monitoring system, digitalized stepping instrument display, high man-machine interaction and is convenient for detection and maintenance; the entire machine control has automatic cruise function, which can get engine operated in setting speed and thus reduces the labor strength of operation person. |
| Motor Grader G9200 Specification | ||
| Operationg Mass | kg | 16000 |
| Engine Power | kw | 151 |
| Overall Dimension | mm | 8975*2710*3240 |
| Overall Length(without front blade and rear ripper) | mm | 8975 |
| Max forward speed | km/h | 38 |
| Max backward speed | km/h | 23.5 |
| Speed gear number | six forward, three backward | |
| Max.traction force | Kn | 83 |
| Hydraulic system pressure | Mpa | 21 |
| Balde L*H*T | mm | 4267*635*25 |
| Frong wheel track | mm | 2260 |
| Rear wheel track | mm | 1538 |
| Wheelbase | mm | 6480 |
| Maximun blade lift above groud | mm | 445 |
| Maximun depth of cutting | mm | 787 |
| Blade cutting angle | forward 47o,backward 5o | |
| Fule tank volume | L | 270 |
| Hydraulic oil tank volume | L | 132 |
| Main Specification | G9200 with VOLVO Technology,DDT BF6M1013CP,151KW(202HP),6WG180 Transmission, Meritor Axle,FOPS/ROPS Cabin,Operating Weight:16000kg | |
G9200 Motor Grader
Packing: disassembled in container or based on Customer's demands
Shipping: by ship or by train or by truck
1. High quality at reasonable price
2. Prompt delivery
3. Rich experience
4. Quick supply of spare parts
5. Professional shipping &package
6. Professional after-sales service
>> Professional: Proven technique can prove stable products, brought you smooth experience in importing.
>> High efficiency: we can handle your require swiftly, and will supply good following-service in spare parts for wheel loader.
>> Experienced: 18years export experience can make us skilled the clearance documents for you in short time
Shandong Senxin Construction Machinery Group.
Add:Room1001, Jiarui Building, Linyi City, Shandong Province, China.
Tel: 0086-539-8180952 Fax:0086-539-8180951
Cellphone: +86-13791576235
Vincent XU
Website :
Skype: xdhanbo
whatsapp : +86-13791576235
Email: chinaloader at
----------HAND IN SENXIN, ONE STEP AHEAD----------
Thank you for visiting our products & Looking forward to hearing from you!
