Bulldozer SHANTUI SD13 with ShangChai engine

Name: Bulldozer SHANTUI SD13 with ShangChai engine
Brand: SHANTUI
Availability: InStock

FOB Price

US$ 30,000 - 100,000 / Unit

1 Unit(Min. Order)

Port QINGDAO

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	SHANTUI
Model Number	SD13	Condition	New
Moving Type	Crawler Bulldozer	Machine Weight	13.7 Ton
Dimension(Long * Breadth * High)	449231852950mm	After-sales Service Provided	Overseas third-party support available

Product Description

1.The extended track ensures low ground pressure, high reliability and strong traction, contributing to precise operation;

2.The power shift transmission not only ensures smooth power shift, but also reaches target speeds and carries out directional transfers with a single control lever;
3. The wet steering clutch and brake can extend service life. They work interactively, ensuring quick and flexible steering operations;
4.The single control lever can control all blade actions;
5.The drift sealing in the drive wheel, track roller and carrier roller can prevent dust from entering the track system, as well as lubricant leakage, thereby ensuring a long service life;
6.The hexahedron cab features wide visibility, and the insulation materials in the cab can reduce noise and vibrations;
7.The spin type fuel filter and dust separator, the air filters and the other filtration devices can prolong work time and reduce service time;
8.The comfortable cab seat can adjust upward and downward, forward and backward, meeting any positional needs the operator may have;
9.Side engine operation and the combination of a drive/brake operation system and foot brake makes overall operation of the bulldozer more rapid and convenient

ITEM	UNIT	SD13
L×W×H (Ripper not included)	mm	4492×3185×2950
Operating weight (Ripper not included)	t	13.7
Engine	-	Shangchai SC8D143G2B1
Rated power	kW/rpm	95.5/1900
Gradeability	°	30
Blade type	-	Straight tilt blade Angle blade
Blade width	mm	Straight tilt blade 3185×1090 Angle blade 3475×915
Dozing capacity	m3	Straight tilt blade 3.7 Angle blade 3.4
Ma× drop below ground of blade	mm	590
Lift height of blade	mm	930
Ripper type	-	Three-shank ripper
Ripping depth of ripper	mm	467
Lifting height of ripper	mm	559
Number of carriers (each side)	-	2
Number of track rollers (each side)	-	6
Number of track shoes (each side)	-	38
Width of track shoe	mm	460
Track gauge	mm	1880
Ground length and ground pressure	mm/MPa	2365-0.063
Pitch	mm	190
Forward speed	km/h	0–3.2
		0–5.9
		0–9.8
Reverse speed	km/h	0–3.9
Reverse speed	km/h	0–7.1

Product pictures

Spare Parts

SHANTUI BULLDOZER SD13/SD16/SD22/SD23/SD32/SD42 PARTS:

Our Services

FAQ

About Payment item:

T/T 30% in advance, the balance should be paid before shipment.

Or Letter of Credit at sight.

About after-sale service:

*We supply 1500 working hours or 12 months warranty since the bill of lading date, whichever comes first.

*During the warranty period, we guarantee to provide technical support and

spare parts (caused by quality problem) freely, but the transportation cost shall be borne by the buyer.
