Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Bulldozer > Tiangong 18 Ton Bulldozer T180F
US$ 70,000 - 90,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
SENX
Model Number:
T180F
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI TIANJIN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
T180F Logging Bulldozer Used in ForestUS$ 70,000 - 90,000MOQ: 1 Unit -
Cheapest 165HP Track Bulldozer TY165-3US$ 50,000 - 70,000MOQ: 1 Unit
-
SHEHWA TY165-3 Small Bulldozer for Sale the Price Types of BulldozerUS$ 50,000 - 70,000MOQ: 1 Unit
-
HBXG Crawler Bulldozer TY165-3,/PD401Y/T140-1/SD6/SD6G/SD7/SD7/SD7P/SD8B/ SD9 Are in StockUS$ 50,000 - 70,000MOQ: 1 Unit
-
China SHENWA TY165-3 Bulldozer for SaleUS$ 50,000 - 70,000MOQ: 1 Unit
Place of Origin
Shandong, China
Brand Name
SENX
Model Number
T180F
Condition
New
Moving Type
Crawler Bulldozer
Machine Weight
17900kg
Dimension(Long * Breadth * High)
5360x3970x3063
After-sales Service Provided
Overseas third-party support available
Product Description
Item name :
Tiangong 18 ton bulldozer T180F
Operating weight :17900KGS
Engine : SHANGCHAI / WEICHAI / NT855 .
BULLDOZER PRICE / BULLDOZER D6 / CHINESE BULLDOZER PARTS
| T180F BULLDOZER |
| AWARDED THE ISO9001:2000 SYSTEM CERTIFICATE |
| SPECIFICATION |
| Specification/Blade type Straight-tilt Angle U-Blade |
| Operating Weight (kg) 17900 18200 18500 |
| Min.Ground Clearance (mm) 400 400 400 |
| Min.Turning Radius (m) 3.3 3.3 3.3 |
| Ground Pressure (MPa) 0.065 0.066 0.066 |
| Track Gauge (mm) 1880 1880 1880 |
| Track Gauge (mm) 147.2 147.2 147.2 |
| Grade Ability (°) 30 30 30 |
| TRAVEL SPEED |
| 1st 2nd 3rd 4th 5th |
| Forward (km) 2.6 3.5 4.7 7.0 10.3 |
| Reverse (km) 3.3 4.5 6.1 9.1 |
| ENGINE |
| Model & Type...............NT855 / Shangchai SC11CB200G2B1 / Weichai WD10G200E25, 6-cylinder, in-line, vertical. water-cooled, 4-stroke-cycle, turbo-charged, over valve directs injection |
| Rated Revolution (rpm) ......................................................... 1850 |
| Flywheel Horsepower (HP) .................................................... 180 |
| NT855:6-139.7X152.4 |
| Cylinder Number-BoreX Stroke (mm) Shangchai:6-120.6X152.4 |
| Weichai:6-126X130 |
| Piston Displacement (L) NT855:14 Shangchai:10.5 Weichai:9.73 |
| Min. Fuel Consumption (g/kW.h)........................NT855:212 Shangchai:220 Weichai:218 |
| Max.Torque (Nm/rpm).................................NT855:877/1250 Shangchai:870/1200 Weichai: 920/1100 |
| Starting Method....................................Starting motor 24V 7.5kW |
| TRANSMISSION SYSTEM |
| Main Cluch.................. Wet , multiple-disc, with cut-off brake. hand-manipulated and hydraulic boosted |
| Transmission.................. Bevel gear, constant meshed, forced lubrication, hand-manipulated,5 forward and 4 reverse speeds |
| Bevel Gear.....................Spiral bevel gear, splash lubrication, single-stage speed reduction |
| Steering Clutch......... Wet, multi-disc, spring loaded,hydraulically separated, hydraulic control |
| Steering............Brake Wet, band type, pedal hydraulic booster, with parking brakes |
| Final Drive...... Double reduction of spur gear, splash lubrication |
| HYDRAULIC SYSTEM |
| Pump Type................................................Gear pump 07441-67503 |
| Working Pressure (MPa)..............................................................13.7 |
| System Discharge (L/min)............ 250(at revolution of 1850rpm) |
| Working Cylinder type........................... Double-acting piston type |
| Working Cylinder Lift Number-BoreXRodXStroke (mm)................ 2-110X65X1026 |
| Working Cylinder Tilt BoreXRodXStroke (mm).........160X70X140 |
| UNDERCARRIAGE SYSTEM |
| Type ............................. Swing type of sprayed beam, suspended structure of equalizer bar |
| Carrier Rollers..............................................................2(each side) |
| Track Rollers..7/each side (4-single flange, 3-double flange) |
| Track Type............................. Sealed, assembled single- grouser |
| Number Of Track Shoes............................................ 39(each side) |
| Width Of Track Shoes (mm) ...................................................... 510 |
| Pitch (mm) ................................................................................... 203.2 |
| Length Of Track 0n Ground (mm)............................................2635 |
Packaging & Shipping
Our Services
Our services : Provide good quality machinery in China and spare parts for your machines from China .ZF transmission 4WG200/6WG200 and parts,Hanzhou Advance(Hanchi advacne) 4WG180/6WG180, Weichai ,Yuchai ,Shangchai Engine & Parts.All SDLG parts are available and fast delivery in China.
Company Information
SHANDONG SENXIN TRADE CO.,LTD has been in this sector for 14 years , mainly exporting and distributing China faoums construction machinery and parts , Brands including SDLG ,XCMG ,LIUGONG,XGMA,CHENGGONG,CHANGLIN,SHANTUI,etc .
Our products:
Wheel loader , Hydraulic excavator ,Motor Grader ,Backhoe loader ,Road roller ,Skid steer loader ,Truck crane
Full series parts for those machine are available , please provide parts number to us when you go for the parts.
Engine Parts:
Wechai(WD615,WP6G,td226b...) ,shangchai(C6121) ,Yuchai ,Xichai ,Xinchai ,Cumm1ns.
