Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Bulldozer > SHANTUI SD16 Bulldozer ,17ton ,shangchai Engine
SHANTUI SD16 Bulldozer ,17ton ,shangchai Engine
US$ 1 - 100,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
SHANTUI
Model Number:
SD16
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SHANTUI SD13 Bulldozer ,13.7ton ,shangchai EngineUS$ 1 - 100,000MOQ: 1 Unit -
SHANTUI SD22 Bulldozer ,23.4ton ,shangchai EngineUS$ 1 - 100,000MOQ: 1 Unit
-
SHANTUI SD23 Bulldozer ,24.6ton ,shangchai EngineUS$ 1 - 100,000MOQ: 1 Unit
-
SHANTUI SD32 Bulldozer ,37.2ton ,NTA855 Engine.US$ 1 - 100,000MOQ: 1 Unit
-
SHANTUI SD42-3 Bulldozer ,Operator 37.2ton ,KTA19 Engine.US$ 1 - 100,000MOQ: 1 Unit
Place of Origin
Shandong, China
Brand Name
SHANTUI
Model Number
SD16
Condition
New
Moving Type
Crawler Bulldozer
Machine Weight
17t
Dimension(Long * Breadth * High)
5140*3388*3032mm
After-sales Service Provided
Overseas third-party support available
The SD16 is equipped with a hydraulic drive system with hydraulic control technology and has an advanced structure, providing reliable performance and convenient and flexible operation, making the SD16 an ideal construction machine.
| ITEM | UNIT | SD16 |
|---|---|---|
| L×W×H (Ripper not included) | mm | 5140×3388×3032 |
| Operating weight (Ripper not included) | t | 17 |
| Engine | - | Shangchai SC11CB184G2B1/ Weichai WD10G178E25 |
| Rated power | kW/rpm | 120/1850 |
| Gradeability | ° | 30 |
| Blade type | - | Straight tilt blade U blade Angle blade |
| Blade width | mm | Straight tilt blade 3388×1149 U blade 3556×1120 Angle blade 3970×1040 |
| Dozing capacity | m3 | Straight tilt blade 4.5 U blade 5 Angle blade 4.3 |
| Ma× drop below ground of blade | mm | 540 |
| Lift height of blade | mm | 1095 |
| Ripper type | - | Three-shank ripper |
| Ripping depth of ripper | mm | 572 |
| Lifting height of ripper | mm | 592 |
| Number of carriers (each side) | - | 2 |
| Number of track rollers (each side) | - | 6 |
| Number of track shoes (each side) | - | 37 |
| Width of track shoe | mm | 510 |
| Track gauge | mm | 1880 |
| Ground length and ground pressure | mm/MPa | 2430-0.067 |
| Pitch | mm | 203.2 |
| Forward speed | km/h | 0–3.29 |
| 0–5.82 | ||
| 0–9.63 | ||
| Reverse speed | km/h | 0–4.28 |
| 0–7.59 | ||
| 0–12.53 | ||
| Net Engine Output at Rated RPM | - | 148HP(110.5KW) |
SHANTUI BULLDOZER SD13/SD16/SD22/SD23/SD32/SD42 PARTS:
