30KW Tubular Turbine Hydro Generator water turbine dynamo
- 1000 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- China manufacture Lock sheet Generator QFSN-300-2-20B for Pacitcan TPP material
- Yawing horizontal axis wind generator 25kw
- 2kw Eolica wind generator
- 3KW 360 RPM Permanent Magnet Generator For Wind Turbine Or Hydro Turbine Customized Electric Motor
- 2000W Wind-solar Hybrid Home Wind Power Generation Five-blade portable manufacturers 48v wind generator turbine price
- 300w household small wind generator solar wind energy power generation system micro generator set home use wind turbines price
Product Details
Place of Origin: | Chongqing, China | Brand Name: | Coreltec | Model Number: | CT-GD500 |
Type: | Other, Tubular turbine |
Product Description
30KW Tubular Turbine Hydro Generator water turbine dynamo
1. Description of Tubular Turbine
Tubular turbine has been divided into Bulb tubular and shaft extension tubular according to the arrangement. Suit to low water head 2-25 meters, and with certain big flow, normally divided into fixed blades and adjustable blades turbine. Main components including: runner, draft cone, water chamber, guide vane, bearing, and main shaft. The spiral case could be steel or concrete. The runner diameter we can manufacture is from 80cm to 6.0meters, with rated output 200Kw to 60Mw.
Turbine units normally be horizontal shaft arrangement. Generator equipped with same or different shaft, with Anyway, they will share the same rotating speed. If specially required, a speed increase gear could be equipped between turbine and generator in order to smaller the generator size.
Specification: Fixed blade type: GD; Adjustable blade type: GZ Suitable flow: Q =1.0m3/s- 250m3/s; |
The tubular turbines are the best selection for exploitation of tidal power and hydraulic power with extremely low heads and extremely large flow rates. They have large discharge, high specific and high efficiency, and need less excavation. They have been classified into Bulb, Pit, Siphon and "S" types in the light of their structural types.
Tubular turbine generally has two categories: fully tubular and half tubular. The half Tubular turbine is divided into bulb, pit and shaft extension types, etc.
|
For half Tubular turbine, the generator is separate from the hydro turbine:
Tubular type turbine is actually horizontal installed axial flow turbine. The water from the reservoir flow through bulb head and then enter into the turbine along the passage between the outer wall of bulb body and the powerhouse concrete. The structures of tubular turbine and horizontal type axial flow turbine are basically similar. The differences between Bulb Tubular Turbine and axial flow turbine are the water diversion chamber, water distributor and draft tube. |
2. 500KW Tubular turbine Technical Parameter:
Hydraulic turbine | Turbine Generator | |||||
Design Head(m) | Design flow (m3/s) | Output Power(KW) | Speed(r/min) | Power(KW) | Voltage(V) | Efficiency(%) |
6.7m | 9.16 m3/s | 338KW | 375r/min | 500KW | 6300V | 92% |
6.5m | 11.2 m3/s | 601KW | 375r/min | 500KW | 6300V | 92% |
7.5m | 8.00 m3/s | 549KW | 300r/min | 500KW | 6300V | 92% |
8.5m | 8.34 m3/s | 612KW | 375r/min | 500KW | 6300V | 92% |
Tubular turbine adopts conical water distributor that mainly includes the inner and outer chambers of the guide vane, guide vane, guide vane arm, connecting rod and control ring, etc. The guide blade shaft of conical water distributor is layout into 60 ~ 70 degree angle with the unit shaft. The bearings supporting the guide vane are seated on the guide vane inner and outer chamber. The guide vane composes a conical surface for adjusting the water flow or stooping the unit. In order to reduce the water leakage losses on the guide vane end surface, the surface of the guide vane inner and outer chamber are spherical surface.
|
Advantage:
1. Low MOQ: It can meet your promotional business very well.
2. OEM Accepted: We can produce any your design.
3. Good Service: We treat clients as friend.
4. Good Quality: We have strict quality control system .Good reputation in the market.
5. Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).
Check below for more information on placing an order
1. Inquiry-Professional quotation. |
2. Confirm the price, lead time, artwork, payment term etc. |
3. Freedom sales send the Pro forma Invoice with freedom seal. |
4. Customer make the payment for deposit and send us Bank receipt. |
5. Initial Production Stage-Inform the clients that we have got the payment, and will make the samples according to your request, send you photos or Samples to get your approval. After approval, we inform that we will arrange the production & inform the estimated time. |
6. Middle Production-send photos to show the production line which you can see your products in . Confirm the estimated delivery time again. |
7. End Production-Mass production products photos and samples will send to you for approval. You can also arrange the third party Inspection. |
8. Clients make payment for balance and Freedom Ship the goods .Also can accept payment term-Balance against B/L Copy Or L/C payment Term. Inform the tracking number and check the status for clients. |
9. Order can be say “finish” when you receive the goods and satisfy with them. |
10. Feedback to Freedom about Quality, Service, Market Feedback & Suggestion. And we can do better. |
We adopt standrad exporting package,use environmental protection materials to makesure the package is suitable to long distance transportation.
Our customers have a wider range of processing choices for transportation mode:
By Express ( FedEx, UPS, DHL, TNT, EMS, etc... )
--- Advantage: Fast ( takes about 7 - 10 days in the delivery ), door to door
--- Disadvantage: A little expensive
By Air Transportation
--- Advantage: Fast ( takes about 8 - 12 days ), a little cheaper than Express.
--- Disadvantage: You need to take the goods from the airport by yourself.
By Sea ( Ocean ) Transportation
--- Advantage: Much cheaper than Express or Air transportation.
--- Disadvantage: Slow and you need to take the goods from your destination port by yourself.
