Home > Products > Francis Turbine > Mini Water Turbine Generator Water Wheel Generator

Share|

Mini Water Turbine Generator Water Wheel Generator

Name: Mini Water Turbine Generator Water Wheel Generator
Brand: Royway
Price: Negotiable

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 1000 Set / Sets per Month
Port Shanghai
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Chongqing, China	Brand Name:	Royway	Model Number:	CT-HL110-WJ-50
Type:	Other, Water turbine/hydro generator, Francis Turbine

Product Description

Mini Water Turbine Generator Water Wheel Generator

Francis turbine

Francis turbine is a kind of turbine suit to water head 20-300meters and with certain suitable flow.

It could be divided into vertical and horizontal arrangement. Francis turbine have the advantage of high efficiency, small size and reliable structure.

Horizontal Francis turbine unit, with horizontal shaft, could be 2 or three supports. Which is normally one stair arrangement. Simple structure, easier operation and maintainence.

Vertical Francis turbine unit, with vertical shaft, metal spiral case or concrete spiral case. With adjustable guide vane, and stay ring etc parts, are suit to runner diameter bigger than 1000mm.

Our engineer will select the most suitable Francis turbine for your hydro power project.

1,Suitable water head : 20-300m

2, Output scope : 50Kw -50Mw

3, Runner diameter : 35cm -250cm

4,Runner material : stainless steel

5, Arrangement type : Vertical and Horizontal

Technical Parameter of Francis Turbine

Francis Turbine
Water Turbine					Generator
Model	Water head	Flow(m3/s)	Output Power (KW)	Speed (r/min)	Type	Model	Rated Power (KW)	Power factor	Rated Voltage(V)	Runaway speed(r/min)	Remark
HL110-WJ-42	30.2	0.349	84.4	805	Manual	SFW75-8/493	75	0.8	400	1650	SCR
	49	0.445	176.3	1025	Manual	SFW160-6/590	160	0.8	400	2200	SCR
	68	0.524	274.24	1207	Manual	SFW250-6/740	250	0.8	400	1800	SCR
HL110-WJ-50	28.7	0.482	111.3	659	Manual	SFW100-10/990	100	0.8	400	1320	SCR
	38.8	0.561	178	766	Manual	SFW160-8/740	160	0.8	400	1350	SCR
	45.5	0.608	221.7	830	Manual	SFW200-8/740	200	0.8	400	1350	SCR
	53	0.655	275	895	Manual	SFW250-6/740	250	0.8	400	1800	SCR
	61.3	0.705	353.4	963	Manual	SFW320-6/850	320	0.8	400	1800	SCR
	70.5	0.756	435	1033	Manual	SFW400-6/850	400	0.8	400	1800	SCR
	82.9	0.819	543	1120	Manual	SFW500-6/990	500	0.8	400	1800	SCR
	97.5	0.901	681	1215	Manual	SFW630-6/990	630	0.8	400	1800	SCR
HL110-WJ-60	22.8	0.607	114	489	TT-300	SFW100-12/850	100	0.8	400	900	SCR
	26.3	0.665	142.7	526	TT-300	SFW125-12/850	125	0.8	400	900	SCR
	31	0.702	178	571	TT-300	SFW160-10/740	160	0.8	400	1080	SCR
	35.3	0.077	222.4	609	TT-300	SFW200-10/850	200	0.8	400	1080	SCR
	41	0.841	278	656	TT-300	SFW250-10/850	250	0.8	400	1000	SCR
	48	0.898	352	710	TT-300	SFW320-8/590	320	0.8	400	1350	SCR
	55.5	0.965	440	764	TT-300	SFW400-8/990	400	0.8	400	1350	SCR
	64.9	1.044	546	826	TT-300	SFW500-8/990	500	0.8	400	1350	SCR
	78	1.1	691	905	TT-300	SFW630-6/990	630	0.8	400	1800	SCR
	88.7	1.187	865	965	TT-300	SFW800-6/1180	800	0.8	6300	2100	SCR
	101	1.302	1079	1030	TT-300	SFW1000-6/1180	1000	0.8	6300	2100	SCR
	118.5	1.411	1342	1116	TT-600	SFW1250-1/1180	1250	0.8	6300	2100	SCR
	140	1.563	1705	1213	TT-600	SFW1600-6/1430	1600	0.8	6300	2100	SCR
HL110-WJ-71	60.4	1.41	689	673	TT-300	SFW630-10/1180	630	0.8	6400	1200	SCR
	70.5	1.49	872	727	TT-600	SFW800-8/1180	800	0.8	6300	1350	SCR
	81	1.615	1079	780	TT-600	SFW1000-8/118	1000	0.8	6300	1500	SCR
	95	1.799	1349	844	TT-600	SFW1250-8/1430	1250	0.8	6300	1800	SCR
	113	1.859	1723	921	TT-600	SFW1600-6/1430	1600	0.8	6300	2000	SCR
	128	2.008	2135	980	TT-600	SFW200-6/1430	2000	0.8	6300	2000	SCR
	147.7	2.187	2659	1053	TT-1000	SFW2500-6/1730	2500	0.8	6300	1800	SCR
	176	2.408	3404	1149	TT-1000	SFW3200-6/1730	3200	0.8	6300	1800	SCR
HL110-WJ-84	74.2	2.17	1338	631	YT-600	SFW1250-10/1430	1250	0.8	6300	1200	SCR
	88	2.383	1701	687	YT-600	SFW1600-10/1430	1600	0.8	6300	1200	SCR
	102	2.516	2155	739	YT-600	SFW2000-8/1730	2000	0.8	6300	1500	SCR
	117	2.748	2658	792	YT-600	SFW2500-8/1730	2500	0.8	6300	1500	SCR
	140	3.006	3401	866	YT-600	SFW3200-8/1730	3200	0.8	6300	1500	SCR
	163	3.135	4256	935	YT-600	SFW4000-6/1730	4000	0.8	6300	2000	SCR
	184	3.446	5274	993	YT-600	SFW500-6/1730	5000	0.8	6300	2000	SCR
HL220-WJ-42	23.4	0.951	178	789	Manual	SFW160-8/740	1600	0.8	400	1350	SCR
	27	1.039	222	847	Manual	SFW200-8/740	200	0.8	400	1350	SCR
	31.4	1.072	275	914	Manual	SFW250-8/740	250	0.8	400	1800	SCR
	37	1.185	355	992	Manual	SFW320-8/850	320	0.8	400	1800	SCR
	42.3	1.29	435	1061	Manual	SFW400-6/850	400	0.8	400	1800	SCR
	49.3	1.409	545	1145	Manual	SFW500-6/990	500	0.8	400	1800	SCR
HL220-WJ-50	15.8	1.08	140	546	TT-300	SFW125-10/740	125	0.8	400	1080	SCR
	18.5	1.186	179	591	TT-300	SFW160-10/740	160	0.8	400	1080	SCR
	21.3	1.3	223	634	TT-300	SFW200-10/850	200	0.8	400	1080	SCR
	24.8	1.353	376	684	TT-300	SFW250-8/850	250	0.8	400	1350	SCR
	29	1.486	351	740	TT-300	SFW320-8/990	320	0.8	400	1350	SCR
	33.6	1.633	441	796	TT-300	SFW400-8/990	400	0.8	400	1350	SCR
	39.3	1.711	544	861	TT-300	SFW500-6/990	500	0.8	400	1800	SCR
	45.2	1.827	680.4	924	YT-600	SFW630-6/990	630	0.8	6300	1800	SCR
	52.8	2.011	864	998	YT-600	SFW800-6/1180	800	0.8	6300	1800	SCR
	61	2.2	1080	1073	YT-600	SFW1000-6/1180	1000	0.8	6300	1800	SCR
	71	2.405	1342	1158	YT-600	SFW1250-6/1180	1250	0.8	6300	1800	SCR
HL220-WJ-60	16.8	1.608	224	471	TT-300	SFW200-12/850	200	0.8	400	900	SCR
	19.2	1.758	278	503	TT-300	SFW250-12/850	250	0.8	6300	900	SCR
	22.9	1.955	359	549	TT-300	SFW320-12/990	320	0.8	400	900	SCR
	26.2	2.035	439	588	TT-300	SFW400-10/990	400	0.8	400	1080	SCR
	30.4	2.236	550	633	TT-300	SFW500-10/990	500	0.8	400	1080	SCR
	35.4	2.344	684	683	TT-300	SFW630-8/990	630	0.8	400	1350	SCR
	41	2.546	868	735	YT-600	SFW800-8/1180	800	0.8	6300	1350	SCR
	47.5	2.7988	1077	791	YT-600	SFW1000-8/1180	1000	0.8	6300	1350	SCR

Advantage:

1. Low MOQ: It can meet your promotional business very well.

2. OEM Accepted: We can produce any your design.

3. Good Service: We treat clients as friend.

4. Good Quality: We have strict quality control system .Good reputation in the market.

5. Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).

Check below for more information on placing an order

1. Inquiry-Professional quotation.

2. Confirm the price, lead time, artwork, payment term etc.

3. Freedom sales send the Pro forma Invoice with freedom seal.

4. Customer make the payment for deposit and send us Bank receipt.

5. Initial Production Stage-Inform the clients that we have got the payment, and will make the samples according to your request, send you photos or Samples to get your approval. After approval, we inform that we will arrange the production & inform the estimated time.

6. Middle Production-send photos to show the production line which you can see your products in . Confirm the estimated delivery time again.

7. End Production-Mass production products photos and samples will send to you for approval. You can also arrange the third party Inspection.

8. Clients make payment for balance and Freedom Ship the goods .Also can accept payment term-Balance against B/L Copy Or L/C payment Term. Inform the tracking number and check the status for clients.

9. Order can be say “finish” when you receive the goods and satisfy with them.

10. Feedback to Freedom about Quality, Service, Market Feedback & Suggestion. And we can do better.

We adopt standrad exporting package,use environmental protection materials to makesure the package is suitable to long distance transportation.

Our customers have a wider range of processing choices for transportation mode:

By Express ( FedEx, UPS, DHL, TNT, EMS, etc... )
--- Advantage: Fast ( takes about 7 - 10 days in the delivery ), door to door
--- Disadvantage: A little expensive
By Air Transportation
--- Advantage: Fast ( takes about 8 - 12 days ), a little cheaper than Express.
--- Disadvantage: You need to take the goods from the airport by yourself.
By Sea ( Ocean ) Transportation
--- Advantage: Much cheaper than Express or Air transportation.
--- Disadvantage: Slow and you need to take the goods from your destination port by yourself.
