High efficiency plant piece Coal Ball Tablet Pillow Shape Charcoal Making Machine
1.Brief introduction of the coal ball tablet pillow shape charcoal making machine
Coal Ball Tablet Pillow Shape Charcoal Making Machine through reducer simultaneously transmitted the power to two pressure rollers and made them rotated in opposite directions. In two pressure rollers rotation, materials naturally enter into the ball molds on pressure roller and materials pressure vary from small to large with the rotation of the pressure roller. When the material is rotated to two rollers line contact points, materials pressure has reached a peak. Under enormous pressure, the powder materials are suppressed into finished ball.
The material
(1) Inlet raw material need less than 3mm,the smaller the material, the better the briquettes.
(2) The material can't be mixed with metal material, or the mold is easily damaged.
(3) The raw material moisture need be controlled between 12%-15%.
The Combustion
(1) Energy conservation and environmental protection,no waste gas,clean and health.
(2) Inflammable,high calorific value,4000-6000calories.
(3) By making high-strength aluminum alloy,durable.
(4) Abundant raw materials,low cost,burning a long time.
(5) Briquette machine has been widely applied and the maket is never saturated.
(6) High density and easy to be ignited.
In order to meet the different needs of different customers,our factory has designed different types of mold forCoal Ball Tablet Pillow Shape Charcoal Making Machine and all of the molds are produced by ourselves according to the customer's requirements,meanwhile the mold materials are use durable.
Main parameter
| Type | Dimension |
Max Output(t/h) Coal |
Max Output(t/h) Charcoal |
Motor Powder | Gross Weight(kg) |
| 290 | 1.5*1.25*1.55m | 2-3 | 1-1.5 | 5.5kw | 800 |
| 360(2) | 1.6*1.45*1.65m | 4-5 | 1.5-2 | 7.5kw | 1000 |
| 360(4) | 1.6*1.4*1.82m | 4-5 | 1.5-2 | 7.5kw | 1500 |
| 450 | 2.6*1.7*2.1m | 5-7 | 3-4 | 18.5kw | 3000 |
| 450(hydraulic) | 2.6*2*2.1m | 5-7 | 3-4 | 18.5kw | 3500 |
| 650 | 2.6*3.3*2.3m | 10-15 | 7-8 | 30kw | 5000 |
| 850 | 3.85*2.2*2.3m | 15-20 | 9-10 | 55kw | 8000 |
| 1000 | 3.85*2.6*2.5m | 20-25 | 13-15 | 75kw | 10000 |
Production line
Crusher: The crusher crushing the big size raw material into the required size less than 3mm.
Conveyer: Customer according to their own needs,by adjusting the speed of conveyor belt to decide how muchto feed.
Feeder: Feeder mainly used to send the coal powder from the bunker to the converyor belt in the production process.
Wheel mixer: Using this binder mixer can mixing the liquid binder(special formula) uniformly, then add this liquid binder into carbon powder, to make the finished coal briquettes much stronger, not easy broken, also has smooth surface and long burning time.
Briquette machine: Coal Ball Tablet Pillow Shape Charcoal Making Machine will make the crushed raw materials processed into products of any shape you want.
Dryer:We all know in the process of mix natural binder into coal powder and the final production may contain about water to some extent so we need to dry up briquettes by dryer.
Our Services
Before the sales
1. According to the customer's requirement, provide the most suitable project design, process design and the purchase program.
2. We will guide customers to choose the best and economical machine, recover investment within short time and site inspection.
In the sales
1. Accompany you to check the working conditions of the machine.
2. Lead to visit all of our machines.
3. Dozens of arrange delivery after received customer's advance payment.
After-sales
1. Engineers available to service machinery overseas to help you install, debug, build plant at the same time provide adhesive technology.
2. Guarantee the quality of equipment, when the equipment in the production have any questions we will timely solution for you.
Company Information
Gongyi City Yuxiang Heavy Machinery Co.Ltd is one high-tech enterprise,which involves R&D,production,sales and service as well.In the past 20 years,our main products have Mining series equipment, Charcoal briquette machine series, Carbonization furnace, Coal series equipment,Dryer series equipment, Grinding machine series,feed and fuel pellet making machine oil press machine etc. We would like to recommend suitable equipment according to your requirement. Offering expressway,railway and water conservancy projects the solution of making high grade sand and matched equipment.
