Progressive Cavity Mono Single Screw Pump Used for Sewage Sludge, Paper Pulp, Food,etc.

Progressive Cavity Mono Single Screw Pump Used for Sewage Sludge, Paper Pulp, Food,etc. thumbnail-1
Progressive Cavity Mono Single Screw Pump Used for Sewage Sludge, Paper Pulp, Food,etc. photo-1
US$ 100 - 100 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
EAA
Model Number:
Pump
Contact Supplier Request Quote Chat Now
Jingjiang E-Aasia Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name EAA
Model Number Pump
Theory Centrifugal Pump
Structure Multistage Pump
Usage Other
Power Hydraulic
Standard or Nonstandard Nonstandard
Fuel Gasoline
Pressure High Pressure
Application Maritime

Introduction:

1. G type positive displacement pump single screw progressive cavity pump is compact, small, easy to maintain, well-adapted to medium, stable flow, also with small pressure fluctuation.

2.Pump has metal lined with rubber stator, which is made of various elastic material, such as NBR rubber, Silicon rubber.

3.G type screw pump could pump high viscosity fluid and medium with hard suspended solid/fiber as well.

4.This pump is widely used in construction field, foodstuff and beverage industries by adopting silicon rubber stator.

5.Pump may equipped with gear box motor, electric magnetic speed adjustable motor, CVT motor, frequency inverter motor, etc.



Performance data:

Working Principle: Single Screw, Progressive Cavity
Main applications:        Oil, Slurry, food
Driver: Electric motor
Power Specs: 220V, 240V, 380V, 400V, 415V, 440V,etc  50hz/60hz
Max.permissible fluid temperature: 120°C(248°F)
Type of connection: Flange or Clamp
Installation position: Horizontal
Casing material Cast iron, Stainless Steel
Stator material NBR, FKM(FPM), Food grade rubber
Shaft seal type:   Packing seal or Mechanical seal
Maximum viscosity: 1×106C.S.T
Maximum drive rating:  90KW(120HP)
Maximum caliber:   250mm(10inch)
Maximum discharge-side pressure: 0.6(6Bar) or 1.2MPa(12bar)
Flow rate range:   0.8-150m3/h(3.5-660US.GPM)



Performance data:



Excellent product made of carefully selected high-quality materials:
Pictures:

Model Capacity Pressure Speed Motor power Head (NPSH)r Inlet Outlet Max grain   diameter Max fiber length
(m3/h) (MPa) (r/min) (KW) (m) (m) (mm) (mm) (mm) (mm)
G20-1 0.8 0.6 960 0.75 60 4 25 25 1.5 25
G20-2 1.2 1.5 120
G25-1 2 0.6 960 1.5 60 40 32 2 30
G25-2 1.2 2.2 120
G30-1 5 0.6 960 2.2 60 50 40 2.5 35
G30-2 1.2 3 120
G35-1 8 0.6 960 3 60 65 50 3 40
G35-2 1.2 4 120
G40-1 12 0.6 960 4 60 80 65 3.8 45
G40-2 1.2 5.5 120
G50-1 20 0.6 720 5.5 60 4.5 100 80 5 50
G50-2 1.2 7.5 120
G60-1 30 0.6 720 11 60 5 125 100 6 60
G60-2 1.2 15 120
G70-1 40 0.6 720 11 60 150 125 8 70
G70-2 1.2 18.5 120
G85-1 65 0.6 630 15 60 150 150 10 80
G85-2 1.2 30 120
G105-1 100 0.6 500 30 60 200 200 15 110
G105-2 1.2 55 120
G135-1 150 0.6 400 45 60 250 250 20 150


progressive cavity mono single screw pump used for sewage sludge, paper pulp, food,etc.progressive cavity mono single screw pump used for sewage sludge, paper pulp, food,etc.progressive cavity mono single screw pump used for sewage sludge, paper pulp, food,etc.progressive cavity mono single screw pump used for sewage sludge, paper pulp, food,etc.





progressive cavity mono single screw pump used for sewage sludge, paper pulp, food,etc.
