Product Description
High Efficiency Fgd Slurry Pump DesulfurizationPump
Production Overview
The pump restricting parts adopt the advanced flow simulation technology to guarantee the reliable pump design and the high operating efficiency.
The anti-corrosion & anti-wear metal and rubber materials which are specifically developed for FGD pumps have been proved by the practice that they can ensure the long-life pump operation. Through adjusting the bearing components to change the impeller position in the pump chamber all-time high-efficient operation of the pump can be achieved. The pump is characterized by the back knock-down structure which is simple and advanced.
It is easy to maintain and repair and it is on need dismantling inlet and outlet water pipes. The containerized mechanical seal specially used for the desulphurization process is adopted and its operation is reliable.
Main Features
A) The wet parts adopt the advanced flow simulation analysis in the design process to guarantee the reliable performance, high efficiency of the pumps. The customer can make the pump always running in an efficient operation state by adjusting the bearing components in the pump impeller to suit the cavity position of the pump.
B) The pumps are designed with rear-assemblage structure system. They are featured by easy structure and it is easy to repair without dismantling the inlet and outlet pipe of the pump. End bearing adopts imported tapered roller bearings and driving end uses two cylindrical roller bearings with thin oil lubrication. It can promote the bearings? ? Working condition to prolong the service life of bearings.
C) Mechanical seal is designed according to the structure characteristic of desulphurization pump, slurry characteristic and the application characteristic. It is cartridge mechanical seal. It has good performance, long service life.
D) The FGD (Flue Gas Desulfurization) equipment of the pump is made of a new type of material A49 duplex stainless white iron which is specially developed by our company itself. The new material has significant corrosion-resistant and wear-resisting performance. The pump, pump cover and splice plates are pressure parts and made of ductile cast iron. The impeller and suction cover is made of the A49 dual-phase stainless white iron. The material of cover plate liner, frame plate liner, and rear liner is natural rubber with natural good abrasion performance, light weight, relatively low cost.
D) The FGD (Flue Gas Desulfurization) equipment of the pump is made of a new type of material A49 duplex stainless white iron which is specially developed by our company itself. The new material has significant corrosion-resistant and wear-resisting performance. The pump, pump cover and splice plates are pressure parts and made of ductile cast iron. The impeller and suction cover is made of the A49 dual-phase stainless white iron. The material of cover plate liner, frame plate liner, and rear liner is natural rubber with natural good abrasion performance, light weight, relatively low cost.
Main Usages
It is mainly applied in the power plant for the absorption tower circulation pump to transmit corrosive slurry.
Power plant, steel plant for flue gas desulphurization.
Technical Data
DT SLURRY PUMP PERFORMANCE PARAMETERS
Company Information
E-ASIA IMPORT & EXPORT Co., Ltd is a professional slurry pumps manufacturer in China,which located at the hometown of Chinese pump---xinqiao, jingjiang, Cover area more than 38 thousand square meters. Different levels quality offeredWe engage in heavy duty and severe duty material handling solutions.
It is mainly applied in the power plant for the absorption tower circulation pump to transmit corrosive slurry.
Power plant, steel plant for flue gas desulphurization.
Technical Data
DT SLURRY PUMP PERFORMANCE PARAMETERS
Company Information
E-ASIA IMPORT & EXPORT Co., Ltd is a professional slurry pumps manufacturer in China,which located at the hometown of Chinese pump---xinqiao, jingjiang, Cover area more than 38 thousand square meters. Different levels quality offeredWe engage in heavy duty and severe duty material handling solutions.
Our slurry pumps are manufactured to be the best standards, ensuring longer service life, higher performance, ease of operation and maintenance. The pumps are widely used in mining, construction, metallurgy, power plant, sewage water treatment, dredging, and chemical and petroleum industries.
| Model | Allowable mating max power | Flow | Head | Speed | Max Efficiency | NPSH | Allowable max partical | Pump Weight |
| N(kw) | Q(m3/h) | H(m) | n(r/m) | η(%) | (m) | (mm) | T(kg) | |
| 800DT-A90 | 900 | 3142-9700 | 6.0-28.7 | 300-592 | 89.3 | 2 | 181 | 5900 |
| 700DT-A84 | 630 | 2157-7360 | 5.2-24.5 | 300-591 | 88.8 | 2.0 | 168 | 5420 |
| 600DT-A82 | 500 | 1664-5600 | 5.2-27.8 | 300-595 | 88.3 | 2.2 | 152 | 4900 |
| 500DT-A85 | 400 | 1036-4080 | 5.7-26.8 | 300-591 | 84.7 | 3.1 | 135 | 4500 |
| 350DT-A78 | 500 | 720-2865 | 11.6-51.1 | 400-740 | 78 | 3.5 | 104 | 3700 |
| 300DT-A60 | 400 | 580-2403 | 8.9-53.1 | 490-989 | 81.1 | 4.3 | 96 | 2790 |
| 200DT-B45 | 90 | 138-645 | 5.7-31.0 | 490-990 | 80.8 | 2.0 | 51 | 1750 |
| 150DT-B55 | 132 | 139-630 | 11.3-53.7 | 490-990 | 78.1 | 2.3 | 56 | 1540 |
| 150DT-A50 | 90 | 62-279 | 9.3-44.6 | 490-980 | 65.7 | 2.1 | 30 | 1470 |
| 150DT-A50 | 90 | 63-279 | 9.3-44.6 | 490-990 | 65.7 | 2.1 | 30 | 1470 |
| 150DT-A40 | 132 | 122-503 | 11.2-61.2 | 700-1490 | 73.1 | 2.6 | 40 | 830 |
| 100DT-A45B | 90 | 41-219 | 12.1-76.4 | 700-1480 | 51.8 | 2.4 | 24 | 800 |
| 100DT-B40 | 75 | 61-268 | 12.0-61.0 | 700-1480 | 70.4 | 1.7 | 29 | 620 |
| 100DT-A35 | 75 | 77-323 | 8.8-45.9 | 700-1480 | 70.4 | 1.9 | 42 | 550 |
| 80DT-A36 | 37 | 41-167 | 8.9-47.1 | 700-1480 | 62.4 | 1.5 | 16 | 480 |
| 65DT-A40 | 55 | 34-159 | 12.2-63.2 | 700-1480 | 62.1 | 2.1 | 16 | 490 |
| 65DT-A30 | 22 | 21-99 | 7.0-35.6 | 700-1470 | 54.6 | 2.2 | 19 | 260 |
| 50DT-D40 | 30 | 16-76 | 9.5-51.7 | 700-1480 | 45.1 | 1.2 | 10 | 320 |
| 50DT-A30 | 18.5 | 16-78 | 6.1-36.3 | 700-1460 | 48.5 | 0.8 | 16 | 210 |
| 40DT-A25 | 45 | 16.8-74.7 | 13.7-88.6 | 1400-2950 | 42.5 | 2.6 | 9 | 185 |
| 40DT-B20 | 15 | 7.9-37.1 | 10.7-57.5 | 1400-2930 | 53 | 0.9 | 7 | 160 |
| 40DT-A19 | 15 | 7.8-34.9 | 12.3-57.1 | 1400-2930 | 58.8 | 1.2 | 11 | 173 |
| 40DT-A17 | 7.5 | 4.6-23.4 | 9.2-44.6 | 1400-2900 | 52.4 | 2.5 | 11 | 127 |
| 25DT-A25 | 4 | 4.7-19.9 | 3.3-21.6 | 700-1440 | 38 | 3.3 | 5 | 107 |
