Newest design biomass rotary dryer with heat supply of chicken manure and cow dung and sawdust etc
>>. What you need to know
1. Rotary Dryer is mainly to dry biomass or Fertilizer or animal feed powder materials , it has rotary drum and can dry high humidity materials, such as sawdust, straw, stalk, animal feed materials from maize, soybean,cereal fertilizer materials from poultry manure , home or factory waste etc .
2. rotary drum dryer drum RPM can be controlled according to raw materials humidity. If humidity is large, then can control feeding speed lower and drum RPM lower to make longer drying time.
3. Rotary Dryer has temperature adjusting equipment between stove and dryer, which can adjust hot air temperature when feeding to dryer drum according to raw materials humidity and outlet stove hot temperature.
4. Rotary Dryer has two ways to discharge materials, one is to outlet from rotary drum bottom, it is mainly fit for large weight ratio materials , the other is to outlet materials from cyclone bottom , which mainly fits for light materials . so please tell us what kind of raw materials and dimension, raw humidity, then we will help you choose best dryer model.
>>. Advantage of Rotary Dryer
1. Reasonable design of raising board and angle ensure the material well-distributed and dry with less time. It owns reliable operation and high energy utilization ratio, simple maintenance.
2. Adopt an adjustable center tug structure, the good cooperation of the tug and the rolling ring reduce the attrition and energy consumption.
3. Special structure of the dam-wheel decrease the horizontal thrust, when the machine working in inclination station, it has strong ability of anti-overloading, steady operation and high reliability.
4. High temperature resistance. It can use the high temperature to dry the material quickly,
5. Large capacity, few fuel consumption, low drying cost
>>.Rotary dryer length 24 meters was divided into two parts
>>.Rotary dryer can also choose biomass pellet burner as its heat sources, we can offer walls stoping the fire.
>>. Technical Parameter of Rotary Dryer
Model | Inner diameter (mm) | Power(kw) | Evaporation (t/h) | Feed water | Discharge water | Inlet temperature | Outlet temperature | Weight(t) |
YGHG0.8*12m | 800 | 5.5 | 0.2-0.3 |
20-50% |
10-20% |
400-600°C |
60-90°C | 3 |
YGHG1.0*12m | 1000 | 7.5 | 0.4-0.5 | 3.5 | ||||
YGHG1.2*12m | 1200 | 7.5 | 0.4-0.5 | 4.2 | ||||
YGHG1.4*12m | 1400 | 7.5 | 0.6-0.8 | 4.8 | ||||
YGHG1.5*12m | 1500 | 7.5 | 0.8 | 6.2 | ||||
YGHG1.6*12m | 1600 | 7.5 | 0.8-1 | 6.8 | ||||
YGHG1.6*24m | 1600 | 15 | 1-0.2 | 12.8 | ||||
YGHG1.8*12m | 1800 | 11 | 0.8 | 7.2 | ||||
YGHG1.8*24m | 1800 | 15 | 1 | 14.8 | ||||
YGHG2.0*12m | 2000 | 11 | 1.2 | 14.2 | ||||
YGHG2.0*24m | 2000 | 15 | 1.5 | 25.9 | ||||
YGHG2.2*12m | 2200 | 18.5 | 1.2 | 14.5 | ||||
YGHG2.2*24m | 2200 | 22 | 1.8 | 28 | ||||
YGHG2.5*12m | 2500 | 18.5 | 1.5 | 15.8 | ||||
YGHG2.5*24m | 2500 | 22 | 1.8 | 23.8 | ||||
YGHG2.8*12m | 2800 | 30 | 1.8 | 16.7 | ||||
YGHG2.8*24m | 2800 | 37 | 2.4 | 31.5 |
>>. Clients' Cases of Rotary Dryer YHGH 2.2*24M
>>. What we need to know
Please let us know the following basic information for making project
1. What are the materials do yo want to dry?
2. What capacity do you want for an hour?
3. What is the water content before drying?
4. What is the water content after drying?
Rotary Dryer Production Line Certificates
3Designed for customer according to his warehouse size and machines list
>>.Company Information
Until now,we have agent in Finland, Belgium, Bulgaria, Egypt, Italy, Thailand, Vietnam, Malaysia
who can sell products and also do after-sales service.Kindly contact us for more details.
>>.Contact Informationy Lei
Wish you have a nice day!
Please leave an inquiry below to know more details about the video of
the production line,the price,packing,shipping,and discount,etc.We can reply at the firsttime.
