Specifications
Mesh belt dryer:Fit for drying briquettes.
Widely used in briquetting plant.
Favourable price.
Delivery in time.
Briquette mesh belt dryer:
The Mesh belt dryer is a kind of batch, continuous production drying equipment, mainly for better ventilation sheet, strip, granular materials, such as: preserved fruit, pepper, potato chips, ball games, grain straw, wood, etc. Also can be used for drying briquettes, with better drying efficiency, widely used in briquetting line, the main heating electric heating, steam heating, hot air heating.
Main specification:
Model | KHWD6 | KHWD8 | KHWD10 | KHWD12 | KHJWD16 | KHWD20 | KHWD24 | KHWD30 |
width of Net belt(mm) | 600 | 800 | 1000 | 1200 | 1600 | 2000 | 2400 | 3000 |
Length of drying section(m) | 6-12 | 6-12 | 6-16 | 8-16 | 8-22 | 10-26 | 12-30 | 12-40 |
Length of feeding section(m) | 1 | 1 | 1 | 1 | 1 | 1.5 | 1.5 | 2 |
Length of transmitting section(m) | 1 | 1 | 1 | 1 | 1 | 1.5 | 1.5 | 2 |
Drying area(m2) | 3.6-36 | 4.8-48 | 6-80 | 7.2-96 | 12.8-105.6 | 20-260 | 28.8-360 | 36-600 |
Unit mumber | 1-5 | |||||||
Interlamellar spacing (mm) | 400-600 | |||||||
Carrying capacity | 90-200 Kg/m2 | |||||||
Operation temperature (°C) | carbon steel≤400 C°,stainless steel≤600 C° | |||||||
Drying strength((kgH2O/h) | 5-20kg H2O/m2.h | |||||||
heat source | hot wind,electricity,steam | |||||||
Running speed | 0.06-1m/min | |||||||
Transmission powder(kw) | 1.1-2.2 | 1.1-2.2 | 1.1-2.2 | 1.1-3 | 1.5-3 | 1.5-4 | 3-7.5 | 5-11 |
Remarks: Based on different materials, capacity, moisture content, the technical parameter is adjustable.
Zhengzhou Kehua Industrial Equipment Co., Ltd is a manufacturer for producing complete roller pressing machine, briquetting machine, briquetting plant, coal briquette machine, briquettes dryer such as mesh belt dryer, chain plate dryer, raw material rotary drying machine etc. Our factory had more than 10 years in manufacturing briquetting line. Our machines are with ISO9001:2008 & CE &GOST certificate, reliable performance with competitive price. Exported to Malaysia, India, Philippine, Northern Ireland of United Kingdom, Indonesia, Australia, Israel, Moldova, Oman, Egypt, United States, Russia, South Africa, Morocco, Middle East, Dubai etc.
