Rotary Dryer
Use of Rotary drum dryer:
Rotary drum dryer is a drying process ( drying equipment ) specially installed for reduce the
moisture of food materials . it is the key equipment that should be take care of choosing ,
Rotary Dryer will the good choice for the food rotating cylinder drier; sawdust drier; powder
drying machine ; direct drying machine ..etc.
Principle of Rotary drum dryer:
Rotary drum dryer consist of a horizontally inclined rotating cylinder. Material is fed at one
end and discharged at the other end. In direct type rotary dryers, hot gases move through the
cylinder in direct contact with the material, either with or against the direction of its flow. The
cylinder is equipped with flights, which lift the material and shower it down through the hot gas
stream.
Features of Rotary Drying Machine:
1. Our slag rotary drying machine is designed with anti-sticky drumwall and assembled material-lifting board.
2.This slag rotary drying machine is divided into secondarygranulating section, balling section,
polishing section and drying section, etc. What worth mentioningis that our slag rotary drying
machine features convenient installation and transportation as a result of its flange connection.
3. This large sized slag rotary drying machine is primarily composed of vibrating feeder, heating
furnace, drying device, and air intake and air outlet device, and more.
4. Our slag rotary drying machine has the features of low noise, little pollution and good drying
effect.
Main Technical Parameters:
Model | Gradient (°) | Speed (R/min) | Volume (m³ ) | Power (kw) | Capacity (t/h) | Weight (t) |
Φ0.6×8m
| 3-5 | 8 | 2.26 | 4 | 1-3 | 2.9 |
Φ0.8×10 m
| 3-5 | 7.2 | 5.02 | 4 | 4-6 | 4.5 |
Φ1.0×10 m
| 3-5 | 6.73 | 7.85 | 5.5 | 5-8 | 5.6 |
Φ1.2×12 m
| 3-5 | 5.8 | 13.31 | 11 | 8-12 | 14.8 |
Φ1.5×12 m
| 3-5 | 4.8 | 21.2 | 15 | 10-15 | 17.8 |
Φ1.8×14 m
| 3-5 | 3.2 | 48.22 | 30 | 12-18 | 27 |
Φ2.2×18 m | 3-5 | 3 | 70.43 | 37 | 15-20 | 53.8 |
Φ2.4×20 m
| 3-5 | 2.83 | 90.43 | 45 | 20-25 | 60 |
Φ2.8×24 m
| 3-5 | 2.59 | 147.8 | 75 | 25-30 | 67 |
Φ3×20 m
| 3-5 | 1.5-5 | 141.3 | 55 | 25-35 | 78 |
Φ3×25 m
| 3-5 | 1.5-5 | 176.6 | 75 | 32-40 | 104 |
