Selective Crushing Effects Counterattact Hammer Crusher

Selective Crushing Effects Counterattact Hammer Crusher photo-1
Selective Crushing Effects Counterattact Hammer Crusher photo-2
Selective Crushing Effects Counterattact Hammer Crusher photo-3
US$ 31,460 - 31,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Counterattact crusher
Application:
Sand, stone and mineral
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjing Qingdao Shanghai Major inland ports
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, Counterattact crusher
Application Sand, stone and mineral
Motor Type AC Motor
Power(W) 110000
Capacity(t/h) 70-120
Place of Origin Henan, China
Brand Name Hongyun
Model Number PF-1210
Dimension(L*W*H) 2582*2053*2809mm
Weight 17t
Certification ISO,CE
Warranty 1 year warranty
After-sales Service Provided Engineers available to service machinery overseas

Simple structure and high quality counterattact hammer crusher

Product Description

The counterattack hammer crusher is a more neoteric crushing machine at present. It is loved by many users because of the advantages of its small size, strong crushing effectiveness, less energy consumption and so on. The fine effect of the counterattack hammer crusher is obvious to users. In the process of use, it can crush materials with below medium hard degree to reach the uniform effect of discharging, and that is the crushing ability which other equipments can't match.

The counterattack hammer crusher mainly uses impact force to do main crushing work. And it achieves the demanding discharging requirement of granularity and shape by using the particular mode of operation. It can be suitable for fine crushing work of production line for sand, stone and mineral processing. At the same time, it is also involved in the coal, metallurgy, chemical, refractory and other industries.



 Selective crushing effects counterattact hammer crusherSelective crushing effects counterattact hammer crusher

Packaging & Shipping

Packaging:standard container, spare parts will be packed in wooden cases or as per customer's demands

Shipping: the spot 2days, OEM 5~10days





Advantages

1 Easy maintenance

2 Super wear-resistant

3 The working mode of low speed and multi-cavity type makes the crushing work more levels of progressive sense

4 Energy conservation and emission reduction

5 Selective crushing effect

6 Novel design

 Selective crushing effects counterattact hammer crusher

The plate  hammer and counterattack plate of the counterattact crusher



Selective crushing effects counterattact hammer crusher

Selective crushing effects counterattact hammer crusher



Our Services



Company is responsible for one package service including the buyers’ process design, on-site construction guidance, equipment installation and debugging, training technical persons and operators. Three Guarantees, one year warranty, and long-term supply of components.



Company Information

 Hongyun is a modern enterprise which makes scientific research, production and sale integration.The machinery factory has 20 years of production experience and performance in the mineral processing equipment and baking-free brick equipment industry, which changes from state-owned enterprise to private enterpriseWe have been keeping the attitude that only customers are satisfied, can we be satisfied to keep pace with the times. We have many skilled technical persons and experienced after-sales service team, so we can offer customers a full of crushing screening from monomer to solutions. And we can provide customers with professional technology support, reliable supply of spare parts and high quality of after-sales service.







Detail parameters

Model

specification

(mm)

Feed inlet size(mm)

Max Feeding size (mm)

capacity

(t/h)

Motor model

Power

(kw)

Weight

(t)

Overall size

L×W×H

 (mm)

PF-1007

Φ1000×700

400×730

300

35-50

Y250M-6

37

9.5

1800×1600×1800

PF-1010

Φ1000×1050

400×1080

350

50-80

Y315S-6

75

14

2340×2007×2500

PF-1210

Φ1250×1050

400×1080

350

70-120

Y315L1-6

110

17

2582×2053×2809

PF-1212

Φ1250×1200

400×1250

350

70-140

Y315L2-6

132

17.5

2582×2203×2809

PF-1214

Φ1250×1400

400×1430

350

80-160

Y315L2-6

132

22

2582×2403×2809

PF-1315

Φ1300×1500

860×1520

500

90-220

Y2-355M2-6

200

26

2930×2761×3053



 Selective crushing effects counterattact hammer crusher
