Home > Products > Sand making machine > New technology and hot sell sand making machine with good price
New technology and hot sell sand making machine with good price
- 100 Set / Sets per Month
- Qingdao Shanghai Dalian Tianjing Lianyungang All inland ports
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | Hongyun |
Model Number: | VSI1140 | Voltage: | 380v | Power(W): | 200kw*2 |
Dimension(L*W*H): | 5000*2700*3300mm | Weight: | 25.6t | Certification: | CE,ISO |
Warranty: | One year warranty | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
New technology and hot sell sand making machine has export standard package,also can do package as customers' requirements.
Product Description
New technology and hot sell sand making machine
Application:
It is used in mineral processing, ore milling, metallurgy, chemical engineering, power industry, water resource industry and other different industries.
Structure:
It is mainly composed of pedestal, holder, vortex crushing cavity, impeller, distributor, main shaft and other parts.
High wear-resisting polishing head for sand making machine
Package and Shipping:
It has standard export package,also can make special package as customers' requirements.
Our Services:
Company is responsible one package service including the buyers’ process design, on-site construction guidance, equipment installation and debugging, training technical persons and operators. Three Guarantees, one year warranty, and long-term supply of components.
Advantages:
1.Vortex crushing chamber and the impeller can form self circulatory system of internal airflow to provide a natural ventilation for using the device.
2.Using the distributor can improve the performance of the equipment, because it can make the conveying of material more continuous, timing and quantitative.
3.According to the overall usage of sand making machine, it can be deployed dry oil pump to provide oil for bearing parts regularly.
4.With double motor drive, the gearing can run smoothly.
5.With the wear-resisting plate of special material in the crushing cavity of equipment, it can improve usability and wear resistance of the core crushing area.
Specification:
Model | VSI7611 | VSI8518 | VSI9526 | VSI1140 | |
Capacity | Cascade and Center Feeding | 120-180 | 200-260 | 300-380 | 450-520 |
Center Feeding | 60-90 | 100-130 | 150-190 | 225-260 | |
Feeding Size(mm) | Soft Material | 35 | 40 | 45 | 50 |
Hard Material | 30 | 35 | 40 | 45 | |
Rotation Speed | 1700-1890 | 1520-1690 | 1360-1510 | 1180-1310 | |
Power of the Double Motors | 110 | 180 | 264 | 400 | |
Overall Dimension | 3700×2150×2100 | 4140×2280×2425 | 4560×2447×2778 | 5000×2700×3300 | |
Weight | 11.8 | 14.5 | 17.8 | 25.6 | |
Power Supply | 380V,50Hz | ||||
Vibrating Sensor | Inspection scope:0.1-20mm/s can be adjusted continuously | ||||
Lubrication hydraulic station | Power of Double Oil Pump | 2×0.25Kw | |||
Overall dimension | 820×520×1270 | ||||
Power of Oil-box Heater | 2Kw |
Factory:
Company Profile
Gongyi Xiaoyi Hongyun machinery factory has 20 years of production experience and performance in the mineral processing equipment and baking-free brick equipment industry, which changes from state-owned enterprise to private enterprise. We have been being committed to product the coal gangue crusher, shale crusher, fine crusher and slag crusher, and improve constantly their performance and efficiency. Recently, combined with foreign advanced technology, we developed three-warehouse compound crusher and three-warehouse fine crusher, which both make high efficiency and energy saving as the theme.
Gongyi Xiaoyi Hongyun machinery factory has a modern enterprise management system, first-class equipment, perfect detection means, high-quality scientific research persons, high-quality tracking service, and face customers with highly dedicated spirit. It is constantly rated "advanced quality management enterprise" and "value-contract and keep-credibility enterprise" for many years.
We has been keeping the attitude that only customers are satisfied, can we are satisfied to keep pace with the times. We have many skilled technical persons and experienced after-sales service team, so we can offer customers a full of crushing screening from monomer to solutions. And we can provide customers with professional technology support, reliable supply of spare parts and high quality of after-sales service.
