Application:
Ore dryer can dry high wet and high gravity materials, such as kinds of sand, dry-mixed mortar, cement slag, clay, coal gangue, mixture, fly ash, gypsum, iron powder, limestone, coal, ore, Lan carbon and so on.
Structure characteristics:
According to customers’ demands, Hongyun machinery factory can design the gas generator and combustor with elevator, belt conveyor, quantitative feeder, cyclone dust collector, draught fan and other related devices.
Performance characteristics:
The Ore dryer’s investment of Gongyi Hongyun factory is just 20% of imported products. It is made of high quality material which is 3-4 times wear-resisting than ordinary material. It can dry the material with 15% moisture and the ultimate moisture can under 0.5%-1% so that it is the preferred drying equipment for enterprise. This device can improve above 40% thermal efficiency than traditional devices. In the process, there is no air leakage with rigorous sealing. It also has good heat preservation system, the temperature of outer barrel is under 60℃, exhaust gas temperature is under 120℃, out-feeding temperature falls below 60℃.The discharging can be packed directly to reduce the comprehensive energy consumption greatly.
Model | Gradient (%) | Rotate speed (r/min) | Maximum inlet temperature (℃) | Power (kw) | Production capacity (t/h) | Notes |
HY-600 | 3-5 | 3-8 | ≤700 | 3 | Based on the moisture content | The production relates to the heating methods |
HY-800 | 3-5 | 3-8 | ≤700 | 4 | ||
HY-1000 | 3-5 | 3-8 | ≤700 | 4 | ||
HY-1200 | 3-5 | 3-8 | ≤700 | 5.5 | ||
HY-1500 | 3-5 | 2-6 | ≤850 | 11 | ||
HY-1800 | 3-5 | 2-6 | ≤850 | 15 | ||
HY-2000 | 3-5 | 1.5-6 | ≤850 | 18.5 | ||
HY-2200 | 3-5 | 1.5-6 | ≤850 | 22 | ||
HY-2400 | 3-5 | 1.5-5 | ≤850 | 22 | ||
HY-2600 | 3-5 | 1.5-5 | ≤850 | 30 | ||
HY-2800 | 3-5 | 1.5-5 | ≤850 | 37 | ||
HY-3000 | 3-5 | 1.5-5 | ≤850 | 45 | ||
HY-3200 | 3-5 | 1.5-5 | ≤850 | 55 | ||
HY-3400 | 3-5 | 1.5-5 | ≤850 | 75 | ||
HY-3600 | 3-5 | 1.5-5 | ≤850 | 90 |
