Application:
Cray dryer is widely used in building materials, metallurgy,mineral processing,chemical industry,cement, casting and other industries.
Structure characteristics:
Cray dryer is mainly consist of feeding device, feeding chute, roller, air heating furnace, hot air duct, front roll ring, rear roller ring, block roller, gear, lifting board, automatic cleaning device, reducer, motor, sealing device, discharging device, power distribution cabinet and other components.
Performance characteristics:
The investment is lower 20% than imported products.
The wear-resisting of material is 3-4times than ordinary material.
This device can improve above 40% thermal efficiency than traditional devices.
The moisture can under 0.5%-1%
Rigorous sealing.
It also has good heat preservation system, the temperature of outer barrel is under 60℃, exhaust gas temperature is under 120℃, out-feeding temperature falls below 60℃.
The discharging can be packed directly to reduce the comprehensive energy consumption greatly.
Model | Gradient (%) | Rotate speed (r/min) | Maximum inlet temperature (℃) | Power (kw) | Production capacity (t/h) | Notes |
HY-600 | 3-5 | 3-8 | ≤700 | 3 | Based on the moisture content | The production relates to the heating methods |
HY-800 | 3-5 | 3-8 | ≤700 | 4 | ||
HY-1000 | 3-5 | 3-8 | ≤700 | 4 | ||
HY-1200 | 3-5 | 3-8 | ≤700 | 5.5 | ||
HY-1500 | 3-5 | 2-6 | ≤850 | 11 | ||
HY-1800 | 3-5 | 2-6 | ≤850 | 15 | ||
HY-2000 | 3-5 | 1.5-6 | ≤850 | 18.5 | ||
HY-2200 | 3-5 | 1.5-6 | ≤850 | 22 | ||
HY-2400 | 3-5 | 1.5-5 | ≤850 | 22 | ||
HY-2600 | 3-5 | 1.5-5 | ≤850 | 30 | ||
HY-2800 | 3-5 | 1.5-5 | ≤850 | 37 | ||
HY-3000 | 3-5 | 1.5-5 | ≤850 | 45 | ||
HY-3200 | 3-5 | 1.5-5 | ≤850 | 55 | ||
HY-3400 | 3-5 | 1.5-5 | ≤850 | 75 | ||
HY-3600 | 3-5 | 1.5-5 | ≤850 | 90 |
