US$ 9,000 - 12,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Beverage, Commodity, Medical, Chemical, Other
Packaging Type:
Cartons
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Rotary Automatic Stretch Film Wrapping Machine for Packing Line , Wrapping and Supply Top Film Fully AutomaticUS$ 2,850 - 3,500MOQ: 1 Set -
Good Qulity Mobile Pallet Stretch Wrapping Machine for Wrapping PalletUS$ 6,500 - 7,000MOQ: 1 Set
-
Stretch Film Wrapping MachineUS$ 2,850 - 3,500MOQ: 1 Set
-
Full Auto Pallet Wrapping Machine ,stretch Wrappng Machine,unmaul Machine.good Qulity ,5 Years WarrantyUS$ 7,000 - 8,000MOQ: 1 Set
-
Good Qulity Mobile Pallet Wrapping Machine for Wrapping PalletUS$ 6,500 - 7,000MOQ: 1 Set
Condition
New
Application
Food, Beverage, Commodity, Medical, Chemical, Other
Packaging Type
Cartons
Packaging Material
Metal
Automatic Grade
Automatic
Driven Type
Mechanical
Voltage
220V/380V/50HZ
Power
3KW
Place of Origin
Jiangsu, China
Brand Name
Jiajun
Model Number
SM-1600
Dimension(L*W*H)
5x8x3m
Weight
800KG
Certification
ISO9001
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.automatic pallet wrapping machine2.intelligent machine pallet wrapping machine
3.5 years warranty pllet wrapping machine
Welcome to your site, It's so luck to meet you
Advantage:
1.this automatic pallet wrapping machine have great advantage,whole the machine controled by PLC and photoeletric sensor,
so the pallet wrapping machine can work precisely
2.cut &grab film fully automatic after wrapping the pallet
3.Photoeletric sensor measuring pallet ,delivery pallet automatic
4.Independent electric control box ,more safety.
5.Touch screen ,show lot imformation on it ,such us :wraped pallets ,machine situation.
6.frenquency conveter control ,more steady,and good qulity
7.save film very much ,our pallet wrapping machine ,film carriage system can pre-stretch film 300%.
Automatic pallet wrapping machine specification:
| Model | SM-1500 | ||||
| Max packing hight | 2000mm | ||||
| Max packing area | 2000mmx1300mm | ||||
| Max packing weight | 2000kg | ||||
| Turntable diameter | 2000mm | ||||
| Turntable speed | 0-14/min | ||||
| Wrapping speed | 30-40 loads per hour | ||||
| Power supply | 380V/50Hz | ||||
| control type | PLC (Brand:MITUSUBISH or SIMENS) | ||||
| screen | Touch screen | ||||
| frequency converter | SIMENS | ||||
| Measuring pallet | photoelectric sensor (Brand: AUTONICS) | ||||
| automatic type | Fully automatic | ||||
| inpout power conveyor | 2000mm | ||||
| output power conveyor | 2000mm | ||||
| conveyor roller material | SS304 | ||||
| Table hight | 550mm | ||||
| roller diameter | 76mm | ||||
| colour of guard | yellow | ||||
| Guard rail. size | 10000x1000mm(LxH) | ||||
| Turntable motor power | 0.75KW (Brand: CPG) | ||||
| Film frame motor power | 0.4KW | ||||
| consumables | LLDPE(thickness:20-30mic) | ||||
| stretch film percent | 250% | ||||
| Film width | 500mm | ||||
| Film elevation speed | 0-3m/min | ||||
| safety device | Emergency brake button | ||||
| electric control box | Independent electric control box | ||||
| measuring hight | photoelectric sensor | ||||
| Turntable startup mode | Frequency conversion slow start | ||||
| machine size | 6000x2650x2900mm | ||||
| machine weight | 1200KG |
