Recycling Aluminum Cutting Machine

Name: Recycling Aluminum Cutting Machine
Brand: Gaode
SKU: 141042262
Availability: InStock

Jiangsu Gaode Hydraulic Machinery Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Jiangsu, China

Brand Name:

Gaode

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Jiangsu, China

Brand Name Gaode

Model Number HC43 Series

Voltage 21.5MPa

Rated Power 7.5KW--44KW

Certification ISO9001:2008;SGS

Warranty 180 days

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Aluminum Cutting Eqipment
1.Safe & reliable
2.No footing bolts needed
3.Diesel engine can be equipped for power

Aluminum Cutting Machine

Applications:

Applicable in recycling companies, automobile dismantling plants, smelting &casting industry to

Cold-shear section steel and metallic structural parts into acceptable furnace charges.

Features

Adopting hydraulic drive, HC43 series feature simple operation & easy maintenance, it's safe &reliable.

Shear force 9 grades from 63 to 500 tons: Blade length 400mm, 600mm, 700mm, 800mm, 1000mm, 1200mm, 1600mm, 1800mm.

No footing bolts needed in installation: Diesel engine can be equipped for power.

Type	Max Shear Force (TON)	Max Holding Force (TON)	Blde Length(MM)	Max Blade Opening (MM)	Shear Frequency (time/min)	Material Size(MM)	Power (KW)	Operation
HC43-630	63	16	600	280	9-16	30X30 Ø35	7.5	Manual Feeding, manual or automatic operation
HC43-1000	100	16	600	280	9-16	40X40 Ø45	11
HC43-1200	120	20	600	280	9-16	45X45 Ø50	15
HC43-1600	160	25	700	320	9-16	55X55 Ø 63	18.5
HC43-2000	200	25	800	380	9-16	65X65 Ø 75	22
HC43-2500	250	26	1000	480	9-16	70X70 Ø 80	30
HC43-3150	315	42	1200	520	8-16	80X80 Ø 90	37
HC43-4000	400	42	1500	700	8-16	90X90 Ø 100	44
HC43-5000	500	42	1800	900	8-16	100X100 Ø110	44
