Specifications
HBS-630Baler and shear
1.Cut sheet metals into different sizes.
2.Flame cutting
3.Reduce the cost of production
Factory Direct Sale CE Certificate HBS-630 Hydraulic Scrap Metal Baler And Shear
Technical Specification
1 |
Press Box Size(L*W*H)
|
5000*2300*1100mm |
|
||||
2 |
Bale Size(L*W*H)
|
750*650mm |
|
||||
3 |
Hydraulic System Pressure |
25 MPa |
|
||||
4 |
Total Motor |
386.5KW |
|
||||
5 |
Power |
380V/3PH,50Hz |
|
||||
6 |
Blade Length |
880mm |
|
||||
7 |
Shearing Frequency (times/min) |
3-5 time/min |
|
||||
8 |
Capacity(Ton/Hour) |
8-22 |
|
||||
9 |
Max Cutting Force (material Tensile Strength no more than 440MPa) |
Round SteelΦ150mm |
|
||||
Billet 135*135mm | |||||||
Steel Plate 60*600mm | |||||||
10 |
Motor |
Model |
Y315S-4/B35 |
Nominal Power |
110KW |
|
|
Nominal Speed |
1480rmp |
Quantity |
3pieces |
|
|||
11 |
Hydraulic Pump |
Model |
A2F160RPF |
Nominal Pressure |
40MPa |
|
|
Nominal Outflow |
160ml/r |
Quantity |
6 Pieces |
|
|||
12 |
Equipment Outline Dimension
|
14800*3150*5500(Flank Expansion) |
L*W*H |
||||
14800*2500*5500mm(Flank Collapsed) |
L*W*H |
||||||
13 |
Floor Space |
17000*5300mm |
L*W |
||||
14 |
Control System |
PLC Automatic Control |
|
||||
15 |
Cooling System |
Oil-steam heat exchanger |
|||||
|
The Auhentication Certificate
Welcome to Gaode
ISRI 2013 Convention & Exposition
Contact Information:
Miss Tracy Sales Representative Jiangsu Gaode Hydraulic Machinery Co.,Ltd ADD: No. 691 Chengshan Road, Jiangyin City, Jiangsu. China Skype: bellabest4 M: +86 15896491581 (24/7) Fax: +86 510 86993993
|
