HC43-630 Small Shear Cutting Machine For Scrap Metal Fabulous

HC43-630 Small Shear Cutting Machine For Scrap Metal Fabulous photo-1
HC43-630 Small Shear Cutting Machine For Scrap Metal Fabulous photo-2
HC43-630 Small Shear Cutting Machine For Scrap Metal Fabulous photo-3
HC43-630 Small Shear Cutting Machine For Scrap Metal Fabulous photo-4
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
gaode
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai For HC43-630 Small Shear Cutting Machine For Scrap Metal
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Jiangsu, China
Brand Name gaode
Model Number HC43-2000
Voltage 220v or in your demand
Rated Power 22kw
Dimension(L*W*H) 2400*1140*1500
Weight 5.66ton
Certification ISO9001:2008.CE.
Warranty 6months
After-sales Service Provided Engineers available to service machinery overseas
Product Description

HC43-630 Small Shear Cutting Machine For Scrap Metal

 HC43-630 Small Shear Cutting Machine For Scrap Metal Fabulous



Technical Specifications:

No.

TECHNICAL SPECIFICATIONS

1

Max Shear Force

630KN

2

Max Holding Force

160KN

3

Shearing Frequency

9~16 times/min

4

Height of Working Table

740 mm

5

Blade Length

800mm

6

Max Blade Opening

380mm

7

Hydraulic System Pressure

21.5MPa

8

Control System

Hydra-electrical Valves;

Push Button to Control

9

Shearing Material

Size

Round Steel

Ø35MM

Square Steel

30*30 MM

10

Motor

Model

Y180M-4

Quantity

1 set

Nominal Speed

1460rpm

Nominal Power

18.5 KW

11

Hydraulic Pump

Model

80YCY14-1B

Quantity

1set

Nominal Outflow

80ml/r

Nominal Pressure

31.5MPa







Working Flow



Packaging & Shipping

HC43-630 Small Shear Cutting Machine For Scrap Metal Fabulous

HC43-630 Small Shear Cutting Machine For Scrap Metal Fabulous

Company Information

GAODE Hydraulic Machinery has been a trusted name in the waste recycling equipment industry for over a decade as a dedicated Chinese manufacturer of scrap metal recycling equipment, our flagship products includethe shear baler, scrap baler, scrap shear, and recycling crane.



In addition to scrap metal processing equipment, we also supply horizontal baler and vertical baler for compacting plastic, paper, cardboard, straw, textile and more types of wastes.Our company was first inaugurated in 2003.



Our GAODE brand has received critical acclaim both domestically and overseas. As a trusted waste recycling equipment manufacturer, we have successfully passed the certification of both the TUV and the ISO9001 Quality Management System. We are currently in the process of obtaining the approval of European standards such as CE and UL.



Finished Products

HC43-630 Small Shear Cutting Machine For Scrap Metal Fabulous

The Exhibition

Our Certificate

Our Factory

HC43-630 Small Shear Cutting Machine For Scrap Metal Fabulous



Our Services

6months guarantee for whole machine

24hours technical support by email

Calling or door to door service

User manual and detailed video

Contact Information

 Jiangsu Gaode Hydraulic Machinery Co,Ltd.

Apple Zhang

Trademanager:cn200094822

TEL: 86-510-86996082 18921250082

FAX: 86-510-86993993

ADD: NO.691, Chengshan Road, Jiangyin City, Jiangsu Province, China.

FAQ

Q1:Can I add my logo on the machines?

A: Yes,OEM and ODM are available for us.

      But you should send us the Trademark authorization letter.

Q2:How can i get the after-service?

 AWe will send you the spare parts by free if the problems caused by us.

     If it is the men-made problems,we also send the spare parts,but you should pay.

Q3:Do you have inspection procedures for machines?

A:100% self-inspection before packing

Q4:Can I have a visit to your factory before the order?

A:Sure,welcome to visit our factory.
    Here is our factory address:No.691, Chengshan Road, Jiangyin City, Jiangsu Province, China.

Q5: Can we order one set machine?

 A:Yes, you can.
